Transparent Absorbing Wave Temperature and Humidity Vibration Test Chamber
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Transparent Absorbing Wave Temperature and Humidity Vibration Test Chamber is a high-end testing device capable of simulating complex environmental conditions. It is particularly well-suited for reliability verification in fields such as aerospace, aviation, and automotive electronics. By superimposing temperature-humidity cycles with vibration stress, it rapidly exposes potential defects in products during transportation or use.
Standards
JJF 1101 Calibration Specification for Temperature and Humidity of Environmental Test Equipment
GB/T 5170 Inspection Methods for Environmental Test Equipment for Electrical and Electronic Products
Parameters
| Category | Item | Specifications |
|---|---|---|
| Basic Specifications | Nominal Inner Volume | 9.5 m³ |
| Inner Chamber Dimensions | 2700mm × 1800mm × 1950mm (Depth × Width × Height) | |
| Test Environment Conditions | Ambient temperature: 25°C, relative humidity: ≤85% RH, cold water temperature: ≤28°C | |
| Temperature Performance | Temperature Range | -70°C ~ +100°C |
| Temperature Fluctuation | ≤±0.5°C | |
| Temperature Deviation | ≤±2°C | |
| Temperature Uniformity | ≤2°C | |
| Temperature Ramp Rate | - Heating: ≥10°C/min (equivalent load 1000kg, electric heating power 8kW, average across the whole range; ≥10°C/min from room temperature to -55°C, ≥10°C/min from -55°C to 70°C)- In the range of -55°C ~ +85°C, the chamber can withstand an internal heat load of 8000W- In the range of -55°C ~ +85°C, the chamber can withstand an internal heat load of 3500W and an internal cooling air supply of 100kg/h (air temperature: 2~35°C, dew point temperature: ≤40°C) |
