Artificial Turf Abrasion Tester
The Artificial Turf Abrasion Tester is designed to simulate mechanical wear conditions that artificial turf experiences during actual use. By combining controlled rolling and reciprocating motion, the device evaluates the durability and abrasion resistance of turf systems. Featuring a dual-roller structure with independent horizontal and vertical motion systems, it replicates the repeated movements of athletes wearing cleated shoes on turf surfaces, providing reliable testing for quality assessment, product development, and compliance verification.
Applications
You can use this tester to evaluate the abrasion resistance of:
Artificial turf systems for football, rugby, hockey, and other sports fields
Filled and unfilled artificial turf
Various pile structures, including monofilament, fibrillated, and mesh grass
Different synthetic turf fibers such as polyethylene and polypropylene
Type testing, factory inspection, and third-party evaluation of finished turf products
Quality control and acceptance of sports field construction projects
Research on turf wear mechanisms in laboratories and testing institutes
Standards
GB/T 20394-2013: Sports Artificial Turf (China)
BS EN 13672:2004: Determination of Abrasion Resistance of Artificial Surfaces for Sports Areas
BS EN 15306: Determination of Simulated Wear Performance of Artificial Sports Surfaces
FIFA Quality Concept for Football Turf (2006)
FIFA 09: Mechanical Durability and Abrasion Testing Requirements for Artificial Turf
Technical Specifications
| Item | Specification |
|---|---|
| Control System | PLC + Touchscreen operation |
| Display | 7-inch full-color LCD touchscreen |
| Operation Mode | Manual / Automatic |
| Data Output | RS232 interface, supports print output |
| Drive System | Servo motor + Stepper motor + Variable frequency AC motor |
| Main Drive Motor | 1 unit |
| Height Adjustment Motor | 1 unit (Stepper motor) |
| Horizontal Movement Motor | 1 unit (Variable frequency AC motor) |
| Test Accuracy | Dimension D ±0.2 mm; Position P ±2 mm |
| Roller Type | Dual-roller structure |
| Roller Size | 2 × 0.3 m |
| Roller Diameter | 118 ± 5 mm |
| Single Roller Weight | 28.500 ± 500 g (including roller, cleats, and shaft) |
| Abrasion Roller | Cylindrical roller with attached cleats |
| Test Cycles | Adjustable within standard range |
| Test Speed | Adjustable within standard range |
| Power Supply | AC 220 V / 50 Hz |
| Rated Power | 3 kW |
Features
Dual independent horizontal and vertical motion systems realistically simulate multi-directional wear on artificial turf
Dual-roller structure with cleated abrasion rollers meets FIFA and EN standards for simulated wear
Test parameters can be flexibly set on the control interface, accommodating different cycle counts and speeds required by various standards
Drawer-style sample design allows easy replacement, inspection of wear, and topping up of infill material
Trench-shaped collection system recovers excess infill to maintain a clean testing environment
Fully transparent protective enclosure allows real-time observation while ensuring safety and noise reduction
Intelligent control system supports continuous cyclic testing with pause and inspection capabilities
