Scratch Resistance Test machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The Scratch Resistance Test Machine is suitable for a wide range of materials and testing scenarios:
Evaluation of rigid organic materials, plastics, glass, and metals for scratch resistance
Testing coatings, adhesives, and powder coatings for durability and adhesion quality
Assessment of furniture surfaces, countertops, and high-pressure laminates
Comparative studies of protective coatings or similar materials under controlled loading
Specific testing product: Scratch Resistance Test Machine
Standards
The instrument is designed to comply with major international and national standards:
GB/T 17657‑2022 – Test methods for performance of wood-based panels and surface finishes
GB 4943.1 – Information technology equipment – Safety, Part 1: General requirements (Clause 2.10.6.6)
GB 4706.1 – Household and similar electrical appliances – Safety, Part 1: General requirements (Clause 21.2)
AS/NZS 2924.2 – Kitchen countertops and surface materials, Part 2: Abrasion and scratch resistance
ASTM C217 – Test method for abrasion resistance of ceramic glazed tiles
BS EN 438‑2 – High-pressure laminates (HPL) – Physical and mechanical properties, Part 2: Test methods
BS EN 13310 – Kitchen countertops and surface materials – Performance requirements
BS EN 14323 – Furniture surface scratch resistance, wear resistance, and chemical durability testing
DIN 68861‑4 – Furniture surfaces – Mechanical properties, Part 4: Scratch resistance
DIN 53799 – Plastics – Determination of hardness (scratch/indentation method)
Parameters
| Item | Details |
|---|---|
| Control System | PLC + Windows system |
| Operation Interface | 12-inch color industrial computer, embedded, Chinese/English switchable |
| Printing Function | WiFi connection to printer |
| Drive | Stepper motor with gearbox |
| Force Weights | Standard: 5N, 6N, 7N, 8N, 10N (other specifications optional) |
| Test Speed | Factory preset 5 r/min, adjustable 0–60 r/min |
| Scratch Spacing | Adjustable |
| Sample Size | 100 × 100 mm, center hole 6.5 mm |
| Scratch Tip | Standard diamond needle, optional 4.8R or 2.5R |
| Speed Display | Adjustable on industrial computer |
| Machine Dimensions | 550 × 310 × 520 mm |
| Power Requirement | 220V, 60A |
Features
Balanced Beam Design: Ensures consistent load application and controlled scratch formation.
Adjustable Weights: Allows precise control of vertical load on samples.
Arcuate Scratch Generation: Rotating sample disc creates reproducible arc-shaped scratches.
Embedded Industrial Computer: Provides intuitive control and real-time monitoring of speed, spacing, and force.
Customizable Scratch Tips: Standard diamond needle with optional radii to match material hardness.
Wide Material Compatibility: Supports rigid organics, metals, plastics, glass, coatings, and adhesives.
Precision Testing: Capable of evaluating extreme performance and adhesion quality of coatings.
WiFi Printing: Direct output of test results for documentation.
