Outdoor Exposure Test System with Operating Temperature Measurement and Solar Simulator
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
This system is widely applied in photovoltaic performance testing and research, including but not limited to:
Electrical performance testing of crystalline silicon photovoltaic modules (monocrystalline and polycrystalline)
Standard operating condition performance measurement of thin-film photovoltaic modules such as CdTe, CIGS, and amorphous silicon
I-V characteristic testing of photovoltaic modules under Standard Test Conditions (STC)
Performance evaluation of photovoltaic modules under Nominal Operating Cell Temperature (NOCT) conditions
Performance comparison and parameter calibration during photovoltaic module research and development
Factory inspection and consistency quality control of photovoltaic modules
Type testing in third-party inspection and certification laboratories
Photovoltaic device testing and research in universities and scientific research institutions
Standards
(1)GB/T 6495.3 Photovoltaic Devices – Part 3: Measurement Principles for Terrestrial Photovoltaic (PV) Solar Devices with Reference Spectral Irradiance Data
(2)GB/T 9535 Crystalline Silicon Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
(3)IEC 61215 Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
(4)IEC 60904-1 Photovoltaic Devices – Part 1: Measurement of Photovoltaic Current-Voltage Characteristics
(5)IEC 60904-2 Photovoltaic Devices – Part 2: Requirements for Reference Solar Devices
(6)IEC 60904-6 Photovoltaic Devices – Part 6: Requirements for Reference Solar Modules
Parameters
| Item | Technical Requirement |
|---|---|
| Solar simulator classification | Class B or better |
| Spectral distribution | Compliant with GB/T 6495.3 standard solar spectrum |
| STC irradiance | 1000 W/m² |
| STC cell temperature | 25 ℃ |
| NOCT irradiance | 800 W/m² |
| Temperature measurement accuracy | ±1 ℃ |
| Temperature measurement repeatability | ±0.5 ℃ |
| Test mode | Natural sunlight or solar simulator |
| Test parameters | Photovoltaic module I-V characteristics |
Features
Solar simulator compliant with IEC 60904 series standards, ensuring high result comparability
Spectral distribution strictly aligned with GB/T 6495.3 requirements for accurate measurement
Supports both STC and NOCT testing, covering key photovoltaic performance conditions
Test samples and reference devices positioned in the same plane perpendicular to incident light, reducing systematic measurement errors
High-precision temperature monitoring meets stringent photovoltaic standard requirements
Simple and flexible system configuration suitable for both laboratory and outdoor testing environments
