AAA-Class Solar Simulator

Get a quote:

Web: qinsun-lab.com

Email:serving@qinsun-lab。com

AAA-Class Solar Simulator is a high-performance device designed to replicate sunlight for testing and research purposes. It can simulate key parameters of solar irradiation, including intensity, spectrum, color, uniformity, and temporal stability. The simulator is essential for evaluating solar cells, solar water heaters, and other photovoltaic products. The “AAA” designation represents the highest international standard ratings for spectral match, irradiance uniformity, and temporal stability, ensuring highly accurate and reproducible results in material science, photovoltaics, and environmental testing applications.

Application

The AAA-Class Solar Simulator is widely applied across various research and testing scenarios, including:

Photovoltaic Testing:

Efficiency measurements of solar cells (I-V curves, quantum efficiency)

Module aging and reliability tests (PID, LID effects)

Materials Research:

Evaluation of photocatalytic materials

Performance testing of photothermal conversion materials

Environmental Simulation:

Accelerated weathering tests for spacecraft components

UV aging tests for automotive coatings

The simulator supports a wide range of solar energy products, material studies, and environmental simulation experiments.

Standards

The simulator conforms to key international standards, including:

(1) IEC 60904-9:2020 – Photovoltaic devices – Part 9: Solar simulator performance requirements

(2) ASTM E927 – Classification of solar simulators for photovoltaic device testing

(3) JIS C8912 – Solar simulators for crystalline silicon photovoltaic cells and modules

Parameters

ItemSpecification
Wavelength range 300–1100 nm (AM0), 400–1100 nm (AM1.5G)
Spectral irradiance distribution Matches AM1.5G standard within ±25% for AAA class
Irradiance non-uniformity ≤2% over effective test area (≥100 mm diameter)
Temporal stability Short-term ≤0.5%, Long-term ≤2% (Class A)
Light sources Xenon lamp, LED array, halogen lamp with filter
Effective test area 50×50 mm to 200×200 mm (adjustable)
Light collimation Optional parallel light for space simulation experiments
Irradiance intensity Adjustable up to 1000 W/m² standard test conditions
Power supply AC 220V, 50/60 Hz (dependent on configuration)
Control system Real-time feedback for irradiance stability
Uniformity control Integrating sphere or homogenizer system
Temperature stability Maintains consistent irradiance across temperature variations
Spectral calibration AM1.5G filter and software-based spectral correction
Control interface Integrated software for spectral calibration, irradiance adjustment, and multi-region testing

Features

Simulates full solar spectrum, including UV, visible, and near-infrared bands

AAA-class spectral match, irradiance uniformity, and temporal stability

Multiple light source options: xenon lamp, LED array, halogen lamp with filters

Optical homogenizers ensure uniform illumination over the effective test area

Real-time feedback control maintains irradiance stability during long tests

Integrated software allows automated spectral calibration, multi-zone testing, and irradiance adjustment

Optional collimated beam configuration for space environment simulations

Effective area adaptable to different sample sizes, up to 200×200 mm
