Automotive Textile UV Resistance Analyzer
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Textile UV Protection Performance Tester is used to evaluate the ability of textiles, fabrics, and other materials to protect against ultraviolet radiation from sunlight under specified conditions.
Standards
GB/T 18830 Textiles - Evaluation of Ultraviolet Protection
AATCC 183 Transmission or Blocking of Erythema-Weighted Ultraviolet Radiation Through Textiles
BS 7914 Standard Test Method for Ultraviolet Protection of Textiles
EN 13758-1 Test Methods for Ultraviolet Protection of Apparel Fabrics
AS/NZS 4399 Sun Protection Clothing: Evaluation and Classification - Textile UV Protection Performance Test
JIS L1925 Determination of Ultraviolet Shielding Factor of Textile Products
Features
1. Utilizes xenon arc lamps as light sources with high-sensitivity PMT processing
2. Fully computer-controlled with automatic data processing and storage
3. Multiple graphical representations, statistical reports, and analysis capabilities
4. Application software incorporates pre-programmed solar spectral radiation factors and CIE spectral red spot response factors for precise calculation of sample UPF values
Parameters
| No. | Item | Specifications |
|---|---|---|
| 1 | Detection Wavelength Range | (290 ~ 400) nm, accuracy: 0.2% |
| 2 | Wavelength Repeatability | 0.25 nm |
| 3 | SPF Test Range | 1–50+ |
| 4 | Wavelength Interval | 1 nm, 2 nm, 5 nm |
| 5 | Sample Positioning | Fully automatic X-Y positioning |
| 6 | Test Results | COLIPA/ISO in vitro method for UVA-PF/SPF ratio |
| 7 | Power Supply | 220V, 50Hz, 125W |
| 8 | Weight | Approximately 40 kg |
Accessories
1. Host computer 1 unit
2. Computer 1 unit
3. Inkjet printer 1 unit
4. Connection software 1 set
5. USB communication cable 1 piece
6. Product certificate of conformity 1 copy
7. Product user manual 1 copy
8. Delivery note 1 copy
9. Acceptance form 1 copy
Test Procedures
1. System Initialization
Power on the instrument and the computer. Allow the xenon arc lamp to stabilize for the recommended warm-up period to ensure consistent irradiance output. Launch the analysis software and select the desired testing standard (e.g., GB/T 18830).
2. Calibration and Zeroing
Perform a baseline scan with an empty sample holder to calibrate the system's $100%$ transmittance reference. This compensates for ambient conditions and current lamp intensity.
3. Sample Preparation and Loading
Cut the textile sample into the required dimensions, ensuring it is flat and free of wrinkles. Place the sample into the holder. The automatic X-Y positioning system will align the sample for the first measurement point.
4. Measurement and Data Acquisition
Initiate the scan. The instrument will measure the spectral transmittance at specified intervals (e.g., $2text{ nm}$) across the $290text{--}400text{ nm}$ range. The software will repeat this process for different points on the fabric as required by the standard.
5. Report Generation
The software automatically calculates the mean UPF value, UVA transmittance, and UVB transmittance. You can then save the data to the database and print the standardized test report.
