High precision linear reciprocating wear tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
Friction and wear testing of metallic materials.
Wear resistance evaluation of non-metallic materials (plastics, rubber, composites).
Tribological study of surface coatings, platings, and surface-modified layers.
Testing of solid and liquid lubricants’ friction performance.
Analysis of material surface processing effects on friction and wear behavior.
Material failure mechanism and reliability research.
Industrial product quality inspection and process control.
Standards
GB/T 3960-2016 Plastics – Determination of Sliding Wear Properties
GB/T 12444 Metallic Materials – General Friction and Wear Testing Methods
ASTM G133 Linear Reciprocating Sliding Wear Test
ASTM G99 Pin-on-Disk Wear Test (related friction measurement requirements)
ISO 7148 Sliding Friction and Wear Testing (relevant sections)
DIN 50324 General Principles of Friction and Wear Testing
Parameters
| Parameter | Specification |
|---|---|
| Test Load Range | 30–1000 g (weight loading) |
| Automatic Loading Range | 10–200 N |
| Test Load Measurement Accuracy | 0.2% F.S |
| Reciprocating Stroke | 0.5–50 mm (adjustable) |
| Reciprocating Frequency | 2–30 Hz |
| Sliding Speed | 0.1–20 mm/s |
| Heating Furnace Temperature | Room temperature – 300℃ |
| Furnace Sample Size | Φ15–40 mm |
| Load Range in Heated State | 0.3–80 N |
| Friction Force Measurement Range | ≤100 N |
| Wear Load Range | ≤40 g |
| Wear Depth Measurement Range | ±0.5 mm |
| Wear Depth Measurement Accuracy | 0.02 µm |
| Control Method | Computer automatic control |
| Data Processing | Real-time curve display and data storage |
Accessories
| Accessory | Specification / Use |
|---|---|
| Reciprocating Drive Unit | Standard, achieves constant-speed reciprocating motion |
| Friction Fixture | Multiple specifications, for different samples |
| Weight Set | 30–1000 g, manual load application |
| Automatic Loading Module | 10–200 N, stable load control |
| High-Temperature Furnace | Room temperature – 300℃, high-temperature friction testing |
| Wear Measurement Probe | Standard, measures wear volume |
| Control and Analysis Software | Standard, data acquisition and analysis |
