G342 Fabric induction static electrical meter
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
This Fabric Induction Electrostatic Tester is suitable for the determination of the electrostatic properties of fibers, yarns, fabrics, carpets, upholstery fabrics and other fabrics or various plate-shaped finished product under laboratory conditions.
Standards：
FZ/T01042 , GB/T 12703.1 , GB/T 33730, ISO18080-1
Features：
1. Large screen color touch screen display operation, Chinese, English interface, menu -style operation;
2. Special designed high -voltage occurrence circuits ensure continuous and linear adjustment within the range of 0 to 10000V. Disted high -voltage voltage values, high -voltage adjustment intuitive and convenient;
3. The high -voltage occurrence circuit adopts a fully enclosed module structure. The electronic circuit achieves high -voltage turnover and turned on, which overcomes the shortcomings of high -voltage occurrence circuits in domestic products that can easily cause contacts. The use of use is safe and reliable;
4. Any attenuation period of static electrode voltage: 1%to 99%;
5. The timing method and fixed pressure method can be adopted separately. The instrument uses the digital table to directly display the instantaneous peak, half -life value (or residual static voltage value) and attenuation time of high voltage discharge. Easy to operate;
Technical Parameters：
1. Measurement range of static voltage values: 0 ～ 10kV.
2. The half -life time limit: 0-9999.99 seconds, the error is ± 0.1 seconds.
3. Sample disk speed: 1400 rpm.
4, discharge time: 0-999.9 seconds can be adjusted. (Standard requirements: 30 seconds ± 0.1 seconds).
5. Diring distance between needle electrodes and samples: 20mm.
6. Measurement between test probes and samples: 15mm.
7. Sample and size: 60mm × 80mm.
8. Power: 220V, 50Hz, 100W.
9. Dimensions: 600mm × 600mm × 500mm (L × W × H).
10. Weight: about 40kg.
