Textile Wet Adhesion Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
Domestic Standards:
T/CNGA 64-2024: Determination of Wet Adhesion of Clothing Fabrics
FZ/T: Reviewed and pending publication
International Standards:
ISO 105-F: Textiles – Tests for colorfastness – Wet and dry rubbing methods (relevant for adhesion effects under wet conditions)
ISO 13934-1 / ISO 13934-2: Textiles – Tensile properties of fabrics (for evaluating mechanical response during wet adhesion testing)
ISO 105-E04: Textiles – Colorfastness to perspiration (simulates wet fabric-skin interaction)
ASTM D5034: Standard Test Method for Breaking Strength and Elongation of Textile Fabrics (relevant for wet tensile performance)
ASTM D2594: Standard Test Method for Pilling Resistance and Other Related Surface Changes of Fabrics (to indirectly assess wet adhesion effects)
EN 31092: Textiles – Physiological effects – Measurement of water vapor resistance of clothing fabrics (indirectly related to comfort under wet adhesion conditions)
AATCC TM79: Absorbency of Textiles – Evaluating wetting behavior relevant to adhesion and comfort
Product Features
(1) Four-level evaluation system for wet adhesion performance (Level 1: Excellent – Level 4: Poor).
(2) High-precision force measurement with 0.03% FS accuracy.
(3) Adjustable test speed from 1–100 mm/min for versatile testing.
(4) Servo-controlled movement with Panasonic motor and driver for stability and repeatability.
(5) Compact, ergonomic design suitable for laboratory environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum Load | 300 g |
| Force Measurement Range | 0.4% – 100% FS |
| Measurement Accuracy | ±0.03% FS |
| Test Speed | 1–100 mm/min |
| Maximum Displacement | 80 mm |
| Displacement Accuracy | 10 μm |
| Servo Motor / Driver | Panasonic |
| Dimensions (L×W×H) | 545 × 419 × 509 mm |
| Power Supply | AC 220V ±10%, 400 W |
| Weight | 25 kg |
Accessories
Sample clamps and holders
Calibration weights
Servo motor driver interface
Protective covers
Test Procedures / Maintenance
(1) Secure the wet fabric sample on the fixture.
(2) Adjust the test speed and maximum displacement according to the material and standard.
(3) Start the servo motor to measure adhesion force while the fabric is in a wetted state.
(4) Record adhesion force and assign performance level based on four-level system.
(5) After testing, clean the sample holder and surrounding area to avoid residue.
(6) Periodically calibrate the force sensor and servo system to maintain accuracy.
