Vacuum Cleaner Air Performance Testing Equipment
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
TheVacuum Cleaner Air Performance Testing Equipment (Type A Pressure Equalization Chamber)is designed to measure the airflow performance of vacuum cleaners and vacuum cleaner motors with airflow below 40 L/min. You use this system to evaluate key air performance parameters under standardized conditions defined by Type A pressure equalization chamber requirements. Manufactured in compliance with international and national standards, the equipment provides accurate, repeatable, and comparable test results for airflow, suction power, and efficiency. Test data can be automatically recorded and exported via USB, making it suitable for both production and laboratory environments.
Standards
-
IEC 60312-1: Vacuum Cleaners for Household Use – Methods for Measuring the Performance – Part 1: Dry Vacuum Cleaners
-
GB/T 20291.1: Household and Similar Electrical Appliances – Vacuum Cleaners – Part 1: Methods for Measuring Performance
-
IEC 62885-2: Surface Cleaning Appliances – Part 2: Dry Vacuum Cleaners for Household or Similar Use – Methods for Measuring the Performance
-
Type A Pressure Equalization Chamber Designas specified in IEC and GB standards
Features
-
You can perform airflow testing using a standardized Type A pressure equalization chamber
-
Stepless electric throttle valve allows precise airflow adjustment
-
Industrial control computer ensures stable data acquisition and processing
-
Supports simultaneous measurement of electrical and air performance parameters
-
Suitable for both complete vacuum cleaners and vacuum motors
-
USB data export simplifies test record storage and reporting
-
Compact layout with professional laboratory-grade construction
Technical Parameters
| Item | Specification |
|---|---|
| Adjustment Method | Electric throttle valve with stepless speed regulation |
| Pressure Chamber Dimensions | 460×460×250 mm |
| Control Mode | 17-inch industrial control computer display |
| Tester Type | Vacuum cleaner parameter tester |
| Test Voltage | AC/DC 10–300V, accuracy: 0.5% |
| Test Current | AC/DC 0.1A–20A, accuracy: 0.5% |
| Test Items | Voltage, current, power, vacuum level, air volume, suction power, efficiency |
| Vacuum Gauge | Range: -50–0 kPa, accuracy: ±0.075%/±0.05% |
| Equipment Power Supply | 220V 50Hz, 1.5KW |
| Equipment Dimensions | 1850×680×1680 mm |
