45 Degree Flammability Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The 45° flammability tester consists of a control system and a combustion chamber. The sample is mounted on a sample holder in the combustion chamber at a 45° angle. The burner is positioned close to the sample, and the sample is ignited with a flame for a specified time before the burner is withdrawn. The burning behavior of the sample and the flame spread rate on the sample are observed to evaluate the ignitability and flame propagation performance of the sample.
Application
45 Degree Flammability Tester is used to determine the burning characteristics of textiles fabric under controlled conditions. This test method covers the evaluation of the flammability test of textile fabrics as they reach the consumer for or from apparel other than children’s sleepwear or protective clothing.
Standard
ASTM D1230: Flammability of Apparel Textiles (45° Inclined Method)
CFR 16 Part 1610: Flammability of Clothing Textiles (Federal Standard)
GB/T 14644: Textiles – Burning Behavior – 45° Test Determination of Flame Spread Rate
FTMS 191-5908: Flammability of Textiles (Federal Test Method Standard)
CAL TB 117: Flame Resistance of Upholstered Furniture Filling Materials
NFPA 702: Field Flame Test for Textiles and Films
JIS L1091
ASTM F2100 Part 9.5
Product Advantages
Automated Precision: Built-in control system with automatic ignition, timer (0.1s accuracy), and reset for consistent testing.
Adjustable Flame Control: Standard flame height (16mm) with calibrated burner for reliable results.
Standardized Accessories: U-shaped sample holder (152mm × 38mm), bristle device, and flame gauge ensure compliance.
Multi-Industry Application: Tests textiles, toys, soft furniture, and apparel for flame retardancy.
Data-Driven R&D: Provides quantitative data for material innovation and quality acceptance.
Safety Compliance: Meets ASTM, ISO, and federal standards, reducing export certification barriers.
Feature
45° Inclined Testing: Simulates real-world flame spread angles for accurate flammability classification.
Smart Touch Interface: Integrated printer for real-time report generation and data storage.
High-Precision Flow Meter: Ensures stable flame height (16mm ±1mm) and pressure control.
Ventilation System: Rear vent holes (φ12.7mm × 11) and top exhaust (φ12.7mm × 16) optimize airflow.
Sample Fixation: U-type clamp with knob adjustment for specimen thickness (45° tilt angle).
Durable Construction: Stainless steel burner (26# syringe needle) and corrosion-resistant components.
Technical Parameters
| Parameter | Specification |
|---|---|
| Operation Interface | Smart Touchscreen (Built-in Printer) |
| Exhaust Vent (Top) | φ12.7 mm × 16 |
| Observation Window | Transparent (Lucency) |
| Rear Vent Holes | φ12.7 mm × 11 |
| Standard Flame Height | 16 mm (Adjustable) |
| Sample Holder | U-Type, 205 mm × 76 mm (Frame: 152 mm × 38 mm) |
| Ignition Time | 1 s (Adjustable) |
| Sample Rack Adjustment | Knob Control (Thickness Adaptive) |
| Specimen Tilt Angle | 45° |
| Burner Type | 26# Standard Syringe Needle |
| Burner Dimensions | 368 mm (L) × 216 mm (D) × 356 mm (H) |
| Dimensions (L×W×H) | 420 mm × 260 mm × 526 mm |
| Weight | 35 kg |
| Power Supply | AC 220V ±10%, 50Hz |
| Burn Timer Accuracy | ±0.1 s |
