Schopper Abrasion Tester | ASTM ISO Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Schopper abrasion tester is a precision device specifically designed to evaluate the abrasion resistance of fabrics. By simulating friction scenarios in real-world use, it quantifies the surface changes of materials under dynamic friction. It is widely used in textiles, automotive interiors, footwear materials, leather, and other fields, providing crucial data support for material research and development, quality control, and industry standard verification.
Applications
Textile Industry: Evaluating the abrasion resistance of fabrics, carpets, curtains, and other materials to optimize fabric structure and surface treatment processes.
Automotive Interiors: Testing the scratch and abrasion resistance of seat fabrics, headliner materials, and door panel trims to ensure product durability.
Footwear and Leather: Simulating the friction between shoe soles and the ground to test the abrasion resistance of footwear materials; evaluating the abrasion resistance of leather surface coatings.
Research and Teaching: Providing standardized testing methods for materials science, textile engineering, and other fields to support the research and validation of new materials.
Standards
DIN 53863-2： Textiles - Test methods - Test method for abrasion resistance of textile fabrics - Rotating abrasion test
GME 60345： Test method for determining the abrasion resistance of automotive trim materials
GMW 3283： Schopper abrasion test
VW/Audi Central Standard PV 3908： Test method for abrasion resistance of automotive interior materials (e.g., fabrics, carpets)
Features
Rotary Abrasion Mechanism: A specimen clamped on a rotating test head (166° taper angle) maintains line contact with an abrasion block, simulating tangential friction.
Modular Clamping System: Obtuse-angle cone chuck and mounting support ensure secure specimen fixation during high-speed rotation (75 revolutions/minute).
Touchscreen Interface: Real-time control panel with programmable cycles, load settings, and rotation reversal triggers.
Arc Height Adjustment: Built-in gauge for measuring sample deformation post-test, critical for assessing material resilience.
Load Customization: Interchangeable weights (50g–1500g) accommodate diverse testing requirements, from delicate fabrics to heavy-duty materials.
Space-Saving Design: Compact dimensions (325×565×560mm) and lightweight build (35kg) optimize laboratory workspace utilization.
Parameters
| Parameter | Specification |
|---|---|
| Revolutions per Minute | 75 rpm |
| Taper Angle | 166° |
| Mounting Head Declination | 7° |
| Specimen Size | 100 cm² |
| Test Area | 50 cm² |
| Arc Height Adjustment | 0–10 mm (manual/automatic) |
| Load Range | 0.5–25 N (adjustable) |
| Standard Weights | 50g, 100g, 250g, 500g, 1000g, 1500g |
| External Dimensions | 325 (W) × 565 (D) × 560 (H) mm |
| Net Weight | 35 kg |
| Power Supply | 115/240V, 50/60Hz |
| Power Consumption | 130W |
