Auto wire abrasive belt drag grinding machine for lab use
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
TheAuto Wire Abrasive Belt Drag Grinding Machineis designed to evaluate the abrasion resistance of automotive wires under controlled mechanical wear conditions. You can use this equipment to simulate long-term friction between wires and surrounding components, ensuring insulation durability and compliance with automotive standards.
Standards
(1) QC/T 730-2005 – Automotive wire abrasion test
(2) SAE J1128-2005 – Low-voltage primary cable for automotive use
(3) DIN 72551 – Automotive cables standard
(4) ISO 6722 – Road vehicle cables test methods
(5) JASO D 618 – Japanese automotive wire standard
Parameters
| Parameter | Specification |
|---|---|
| Applicable Wire Diameter | ≤15 mm |
| Sand Belt Length Counter | 0–999.999 mm |
| Sand Belt Speed | 1500 mm/min |
| Support Corner Radius | 3.5 mm |
| Test Voltage | 24 V |
| Load | 20 g / 50 g / 100 g / 200 g (2 pcs) / 500 g / 900 g / 1000 g |
| Load Support Weight | 65 g (0.63 N ± 0.05 N) |
| Sand Belt Angle | 29° |
| Conductive Strip Spacing | 75 mm or 150 mm |
| Conductive Strip Width | 10 mm |
| Power | 200 VA |
| Power Supply | 220 V, 50 Hz |
| Abrasive Belt Options | 80#, 150#, 180#, 400# |
Application
This machine is suitable for:
(1) Drag abrasion resistance testing of automotive wires.
(2) Evaluation of insulation durability under continuous friction.
(3) Quality control of wire coating and insulation materials.
(4) R&D testing for automotive electrical wiring systems.
Features
(1)Stable Mechanical Structure– Compact design ensures safe and reliable operation.
(2)Electrostatic Coating Cabinet– Durable surface treatment improves corrosion resistance and service life.
(3)Adjustable Test Conditions– Preset length, adjustable load, and fixed speed enable repeatable testing.
(4)Wide Load Configuration– Multiple weight options simulate different abrasion conditions.
(5)Accurate Abrasion Simulation– Controlled angle and belt motion replicate real installation environments.
(6)User-Oriented Design– Easy parameter setting and operation improve testing efficiency.
