Automotive Wire Combustion Tester
Get a quote：
Whats/App: +86 181 0160 0864
The Automotive Wire Combustion Tester is designed to evaluate the flame resistance and burning performance of automotive wires and cables. It ensures compliance with international standards and helps verify wire safety under fire exposure conditions.
Application
(1) Automotive wire harnesses – assess flame resistance for vehicle safety.
(2) Low-voltage electrical cables – verify compliance with combustion standards.
(3) R&D laboratories – evaluate new wire materials for fire safety.
(4) Production quality control – ensure each batch meets flammability requirements.
(5) Certification testing – for ISO, SAE, DIN, and QC/T compliance verification.
Standards
(1) QC/T703-2005 – Automotive electrical wire flame resistance standard
(2) SAE J1128-2005 – Automotive wire flammability test
(3) DIN 72551 – Wire and cable combustion test
(4) ISO 6722 – Road vehicle electrical cables flame resistance
Parameters
| Parameter | Specification |
|---|---|
| Test Chamber | Enclosed; dimensions: 650 × 450 × 900 mm; stainless steel with matte black background |
| Fuel Gas | High-purity propane or liquefied petroleum gas |
| Test Sample Length | 600 mm (24 in) |
| Sample Clamp Angle | 45° |
| Bunsen Burner Tube | Nominal diameter 9 mm; outer flame: 100 mm (4 in); inner flame: 50 mm (1/2 in); inner flame temperature: 900 ±50°C |
| Burner Position | Below the sample, perpendicular to sample axis |
| Ignition | Automatic |
| Vertical Flame Duration | 15 s |
| Temperature Measurement | High-precision K-type thermocouple with TES-1310 temperature meter |
| Exhaust System | Ventilation fan removes combustion gases after test |
| JIS3005 Horizontal Combustion Fixture | Included; horizontal combustion test setup |
| Horizontal Test Chamber | 305 × 355 × 610 mm |
| Horizontal Sample Length | 300 mm |
| Horizontal Sample Placement | Horizontal |
| Horizontal Flame Duration | 30 s |
| Horizontal Burner Tube Diameter | 10 mm; inner flame: 35 mm; outer flame: 130 mm |
| Stop Method | Automatic when preset data reached |
