Carpet Flammability Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
TheCarpet Flammability Testeris designed to assess the flame-retardant properties of textile floor coverings, including carpets and rugs. It provides precise, repeatable testing under controlled ignition conditions, ensuring compliance with international and national standards for carpet fire safety.
Application
Carpet Manufacturers: Validates flame retardancy of residential/commercial carpets.
Quality Inspection Agencies: Certifies products for fire safety compliance.
Fire Research Institutes: Studies material behavior under controlled ignition conditions.
Construction & Hospitality Sectors: Ensures flooring meets building fire code requirements.
Standard
BS 4790: Hot Metal Nut Method for Floor Covering Fabrics
ISO 6925: Ambient Temperature Tablet Test for Floor Coverings
BS 6307: Fire Test for Textile Floor Materials (Carpets/Rugs)
GB/T 11785: Flame Retardancy of Textile Floor Coverings
Product Advantages
Dual Testing Methods: Supports both hot nut and polymer sheet ignition techniques.
Precision Observation: Sliding panel and ceiling mirror enable real-time sample monitoring.
Automated Control: PLC-driven system ensures consistent test parameters.
Safety First: Flame-retardant test chamber withstands high temperatures.
Pneumatic Clamping: Securely holds samples without manual intervention.
Easy Operation: Intuitive touchscreen simplifies method selection and data recording.
Product Features
Flame-Resistant Chamber: Constructed from heat-resistant boards (380 × 380 × 380 mm).
Hot Nut Ignition: Stainless steel nut (30g, M16) heated to 900°C in a muffle furnace.
Polymer Sheet Method: Includes 230 × 230 mm metal plate with central hole for ignition.
Sliding/Fixed Panels: 280 × 380 mm sliding panel and 100 × 380 mm fixed panel for sample access.
45° Inclined Base: Simulates real-world carpet installation angles.
Safety Interlocks: Prevents chamber access during active testing.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Mode | Automatic (PLC) |
| Test Chamber Size | 380 mm × 380 mm × 380 mm |
| Sample Clamping | Pneumatic (Adjustable Pressure) |
| Metal Plate | 230 × 230 × 6.5 mm (Central Ф205 mm Hole) |
| Ignition Nut | 30 g, M16 (Flat Diameter: 26.75–27.7 mm) |
| Sliding Panel | 280 × 380 mm (Flame-Retardant Glass) |
| Inclined Angle | 45° (Adjustable) |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 70 cm × 80 cm × 120 cm |
| Net Weight | 75 kg |
| Display | LED Touchscreen (Method Selection/Timer/Status) |
