Multifunctional Washability Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Multifunctional Washability Tester is a versatile abrasion testing instrument designed to evaluate the wear resistance of coatings, paints, and surfaces. By changing different friction heads, it meets all linear reciprocating abrasion test standards, including wet washability, sponge abrasion, stain resistance, solvent wipe resistance (alcohol, MEK), scouring pad resistance, and dry rubber abrasion. The instrument features full touchscreen operation, allowing operators to set test parameters directly and monitor the testing process in real time, ensuring convenience and ease of use.
Application
(1) Architectural coatings manufacturers – evaluate paint durability and washability.
(2) Quality control laboratories – ensure compliance with national and international coating standards.
(3) Research and development – test new coatings, varnishes, and decorative materials.
(4) Industrial product testing – assess stain resistance and abrasion performance of surfaces.
(5) Educational and certification institutions – training and demonstration of coating durability testing.
Standards
(1) GB/T 9266 – Determination of Washability of Coatings
(2) GB/T 9780 – Test Method for Stain Resistance of Coatings
(3) GB/T 23989 – Determination of Solvent Resistance of Coatings
(4) GB/T 31410 – Evaluation of Wet Scrub and Cleanability of Paints and Varnishes
(5) GB/T 1770 – Determination of Sanding Properties of Paint and Putty Films
(6) GB/T 7706 – Relief Decorative Printing
(7) ISO 11998 – Determination of Wet Scrub and Cleanability of Paints and Varnishes
(8) ASTM D 2486 – Test Method for Washability of Wall Paints
(9) ASTM D 3450 – Standard Test Method for Washability of Interior Wall Coatings
(10) ASTM D 4213 – Standard Test Method for Abrasion Loss of Coatings
(11) ASTM D 4828 – Standard Test Method for Washability of Organic Coatings
(12) ASTM D 7835-19 – Mechanical Friction Method for Solvent Resistance of Organic Coatings
(13) DIN EN 13300 – Paints and Varnishes – Water-based Coatings for Interior Walls and Ceilings
Parameters
| Parameter | Specification |
|---|---|
| Operating Speed | 5–95 cycles/min (continuously adjustable) |
| Stroke Length | 0–300 mm (adjustable) |
| Number of Cycles | 0–99,999 (programmable) |
| Input Voltage | AC 110V/220V, 50/60Hz |
| Wash Medium Container Capacity | 500 ml × 2 |
| External Dimensions (L×W×H) | 500 × 460 × 280 mm |
| Net Weight | 55 kg |
Features
(1) Dual working channels, each with independent wash medium containers, allowing simultaneous dry and wet friction tests or different media tests.
(2) Stepless adjustable friction speed and stroke to accommodate various test requirements.
(3) Push-rod type friction arms ensure stable and uniform operation for reliable results.
(4) Wash medium flow is adjustable and precisely controlled via peristaltic pumps.
(5) Quick and convenient installation of test panels and interchangeable friction heads.
(6) Main frame and components made of aluminum alloy, ensuring durability and aesthetic design.
(7) Compatible with 110V/220V and 50Hz/60Hz power supply.
