Fabric shrinkage tester for clothing manufacturers
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
It is used to test the dry heat shrinkage performance of tire cord, yarn, polyester, cotton and other materials under certain temperature conditions.
Standard
GB/T9101-5.4-2017:Polyamide 66 dipped tyre cord fabric
GB/T9102-6.8-2016:Nylon 6 dipped tyre cord fabric
GB/T19390-7.4.1-2023:Dipped polyester cord fabric for tyres
ASTM D4974-2002:Standard Test Method for Rubber Thread - Determination of Dry Heat Shrinkage
Features
One machine for dual use, can separately test shrinkage rate and shrinkage force;
The system uses touch screen to carry out man-machine dialogue and input operation directly on the interface;
The temperature module is directly used to collect temperature, the thermocouple is built-in, PID control output heater, and heating temperature and heating speed can be set on the touch screen;
Through the LCD display, can directly display the current test data, while providing data storage function, can query multiple groups of test results, and can calculate the test results;
Equipped with a micro printer to print two values of shrinkage and shrinkage force respectively.
Parameters
| Description | Details |
|---|---|
| Measuring length | 250 ± 1mm |
| Shrinkage measurement accuracy | 0.1% |
| Shrinkage force measurement range | 0 - 25N (can be customized) |
| Measuring accuracy of shrinkage force | 0.1N |
| Heating range | RT - 250°C |
| Temperature control accuracy | ±0.1°C |
| Timing range | 0 - 999S |
| Power supply | AC 220V 50Hz |
| Overall dimensions | 520x370x510mm (assuming the "37" is a typo and should be "370" for consistency in dimensions) |
| Weight | 35kg |
Accessoriess
1. Main unit: 1 set
2. Weights: 8 pieces
3. Weight trays: 2 pieces
4. Fuses: 2 pieces
5. Grounding wire: 1 piece
6. Feet: 4 pieces
7. Packing list: 1 copy
8. User manual: 1 copy
9. Certificate of conformity: 1 copy
