ASTM & ISO Plastic Scratch Test machine Manufacturer & Supplier
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Plastic Scratch Test Machine is a precision testing instrument designed to evaluate the scratch resistance of plastics, films, coatings, and automotive interior and exterior decorative materials. By simulating controlled scratch conditions, it provides accurate, repeatable, and quantifiable data on surface durability, aiding in product development, quality control, and comparative performance analysis.
Standards
The instrument is designed to comply with major international and national standards:
ASTM D7027‑05 – Method for evaluating scratch resistance of polymer coatings
ASTM G171 – Method for determining scratch hardness of materials
ISO 19252 – Scratch durability testing of coating systems
GB/T 23989‑2009 – Determination of scratch resistance of coatings
GB/T 1768‑2006 – Method for measuring abrasion resistance of paint films
Parameters
| Item | Details |
|---|---|
| Dimensions (approx.) | 800 × 400 × 730 mm |
| Power Supply | AC 100V, Max 60W |
| Operating Temperature & Humidity | 10–40°C / 30–70% RH, non-condensing |
| Testing Method | Increasing load method |
| Scratch Direction | Left to right |
| Detector | Force sensor |
| Vertical Load | 1–200 N |
| Horizontal Load | 200 N |
| Accuracy (Full Scale) | ±0.5% or better |
| Scratch Distance | 400 mm |
| Scratch Speed | 1 mm/sec – 400 mm/sec |
| Number of Measurements | Approx. 1000 |
Optional Configurations:
Scratch tip radii: 0.5 mm, 0.75 mm, 1 mm (customizable)
Load weights: 1 N, 2 N, 5 N, 10 N, 20 N, 50 N (customizable)
Test spacing: 100–400 mm ±0.5 mm
Features
Teach Function: High-precision load region setup before sample testing.
Touch Screen Operation: Simple and intuitive control for all test functions.
Adaptable to Uneven Surfaces: Vertical load mechanism with suspension system ensures accurate testing even on irregular surfaces.
Test Condition Memory: Stores up to 20 test profiles for repeated testing.
Built-in Scratch Tips: Enables evaluation of multiple scratch types, including gloss, scale, and cut scratches.
Quantitative Scratch Evaluation: Measures scratch characteristics precisely.
Load-Dependency Assessment: Evaluates load influence in a single test.
Minimal Test Cycles: Requires few tests to assess scratch performance.
Scratch Structure Analysis: Suitable for in-depth surface analysis.
Stable Test Environment: Optimal performance at 10–40°C and 30–70% RH, non-condensing.
Accessories
Scratch tips of various radii (0.5 mm, 0.75 mm, 1 mm)
Custom load weights (1–50 N)
Touch screen controller
Sample holders
Calibration tools and cleaning kit
