Accelerating Rate Calorimeter ARC Battery Test System ASTM E1981
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1)GB/T 36276 - 2023:Lithium-ion Batteries for Electric Power Energy Storage
(2)UL 9540A:Test Method for Evaluating Thermal Runaway Fire Propagation in Battery Energy Storage Systems
(3)ASTM E1981 - 98(2012):Standard Test Method for Thermal Stability of Chemicals by Differential Scanning Calorimetry (DSC)
(4)SN/T 3078.1 - 2012:Guidelines for the Evaluation of Thermal Stability of Chemicals - Part 1: Accelerated Calorimetry Method
(5)USABC SAND99 - 0497:This is a specific test protocol document from the United States Advanced Battery Consortium (USABC), and it doesn't have a widely recognized single "English name" in the same sense as formal standards. It could be referred to as "USABC Thermal Stability Test Protocol SAND99 - 0497"
(6)SAE J2464 - R2009:Electric and Hybrid Electric Vehicle Rechargeable Energy Storage System (RESS) Safety and Abuse Testing
(7)Freedom CAR SAND 2005 - 3123:Similar to USABC SAND99 - 0497. it is a specific technical document from the Freedom CAR program. It could be called "Freedom CAR Thermal Stability Test Document SAND 2005 - 3123"
(8)UL 1973:Batteries for Use In Stationary and Vehicle Auxiliary Power Applications
(9)GB 38031 - 2020:Safety Requirements for Power Batteries of Electric Vehicles
Features
(1)Precision: The self - heating detection sensitivity is far better than the standard detection threshold of 0.02°C/min. It has high thermal insulation performance and a small temperature difference between the wall and the sample.
(2)Efficiency: With an innovative heating wire assisted heating solution, the experimental efficiency can be increased by up to 5 times.
(3)Safety: It is equipped with safety protection measures such as burst discs, pressure relief valves, and explosion - proof boxes. The professional alarm system design comprehensively ensures the safety of personnel and equipment.
(4)Innovation: It has the innovative function of adiabatic thermal runaway - gas production combined analysis, enabling a comprehensive acquisition of the characteristic parameters of battery thermal runaway.
Parameters
| Description | Details |
|---|---|
| Adiabatic chamber effective size | Diameter: 800mm, Depth: 520mm |
| Self-exothermic detection sensitivity | Better than 0.02℃/min |
| Constant temperature wall sample temperature difference | ≤ 1℃ |
| Temperature control range | RT ~ 300℃, with low temperature module up to -25℃ |
| Working pressure range | 0 ~ 2MPa |
| Temperature tracking rate | 0.02 ~ 15℃/min |
| Needle maximum stroke | Stroke can be set up by software |
| Charge and discharge electrode column overcurrent capacity | -1000A ~ 1000A |
Accessoriess
(1)Temperature control and insulation components
(2)Safety and protection components
(3)Gas processing components, etc.
