High Precision Automotive Camera Leak Tester Manufacturer
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1) IEC 60529 (IP Code protection classification)
(2) ISO 20653 (Road vehicle protection standards)
(3) GB/T 4208 (Enclosure protection standard)
(4) IP67 standard (1 meter water immersion for 30 minutes)
(5) IP68 standard (continuous immersion under higher pressure conditions)
Parameters
| Item | Specification |
|---|---|
| Test Method | Pressure decay / Differential pressure |
| Test Pressure Range | 60–500 kPa (customizable) |
| Leak Detection Resolution | Up to 0.1 Pa (differential mode) |
| Test Cycle Time | 8–30 seconds per unit |
| Medium | Clean dry compressed air |
| Control System | PLC + touchscreen interface |
| Fixture Type | Customized sealing chamber |
| Data Output | USB / system export |
Features
(1) High-speed testing suitable for mass production lines
(2) Supports pressure decay and differential pressure testing methods
(3) High sensitivity detection capable of identifying micro-leaks
(4) Customized fixture design for different camera structures
(5) Stable performance under continuous industrial operation
(6) Automatic pass/fail judgment system
(7) Fast cycle time improves production efficiency
(8) Suitable for IP67/IP68 waterproof verification
Accessories
(1) Customized sealing fixture for automotive cameras
(2) High-precision pressure sensor module
(3) Air pressure regulation and filtration system
(4) PLC control and touchscreen interface
(5) Standard leak calibration reference device
