PLC liquid crystal touch impact testing machine (simple suspension)
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
A PLC LCD Touch Impact Testing Machine (Simple Suspension) is a type of pendulum impact tester designed to measure the impact resistance of materials using a simple (pendulum) suspension system, with modern control via a PLC (Programmable Logic Controller) and an LCD touchscreen interface.
Product Introduction
Liquid crystal touch impact testing machine is mainly used for hard plastics (including sheet, pipe, plastic profile)， reinforced nylon, glass fiber reinforced plastic, ceramic, cast stone, electrical insulation materials and other non-metallic materials impact toughness measurement, widely used in the chemical industry, scientific research units, universities and other quality testing departments.
Standards
(1)GB/T 11022-2020. GB/T 3906-2020. JB/T 10840-2008.GB/T 7251.1-2013 ，GB/T 7251.4-2017.GB/T 7251.5-2017 ，GB/T 20641-2014
(2)GB/T 20138-2006 ，GB/T2423.55-2006 ，Q/GDW11008-2013
Main features
Not poor quality: the use of high hardness and high-precision bearings, and the use of shaftless photoelectric sensors, fundamentally eliminate the loss caused by friction, to ensure that the friction energy loss is far less than the standard requirements.
Intelligent prompt: According to the impact of the situation, intelligent prompt working status, always interact with the experimenter, to ensure the success rate of the test.
Friendly interface: there are parameter setting interface - result query interface - measurement interface - system setting interface, each operation has a clear user prompt, you can record 10 test records, you can choose domestic and international standards, you can choose Chinese and English.
Accurate measurement: In full accordance with the provisions of the new standard, after 10 swing cycles for a calculation of energy loss, each measurement to go through 3 times to average, to ensure the accuracy of energy loss.
Performance parameters
1. Simple beam impact testing machine
- Impact speed: 2.9m/s
- Impact energy: 1/2/4/5J
- Maximum friction loss energy: <0.5%
- Pendulum prelift Angle: 150±1°
- Strike center distance: 230mm
- Power supply: 220VAC-15% —— 220VAC+10%, 50Hz(single-phase three-wire system)
2. Cantilever beam impact testing machine
- Impact speed: 3.5m/s
- Impact energy: 1J; 2.75 J; 5.5 J; 11J; 22J(3 hammers, customer's choice)
- Maximum friction loss energy: <0.5%
- Pendulum prelift Angle: 150±1°
- Strike center distance: 335mm
- Power supply: 220VAC-15% —— 220VAC+10%, 50Hz(single-phase three-wire system)
Accessories
(1)Pendulum (Impact Hammer)
Available in different energy levels for various testing requirements.
(2)Charpy Specimen Support (Anvils)
Used to support specimens during Charpy impact testing.
(3)Izod Clamping Fixture
For vertically clamping specimens in Izod impact tests.
(4)Specimen Alignment Device
Ensures accurate positioning of specimens before impact.
(5)Safety Protection Cover
Prevents debris from splashing during testing and ensures operator safety.
(6)Encoder / Angle Measurement System
Used to measure pendulum angle and calculate absorbed energy.
