Single chip liquid crystal touch impact testing machine
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
Liquid crystal touch impact testing machine is mainly used for hard plastics (including sheet, pipe, plastic profile)， reinforced nylon, glass fiber reinforced plastic, ceramic, cast stone, electrical insulation materials and other non-metallic materials impact toughness measurement, widely used in the chemical industry, scientific research units, universities and other quality testing departments.
Standards
(1)GB/T 18910.101-2021
(2)IEC 60068-2-75:2014
Main features
Not poor quality: the use of high hardness and high-precision bearings, and the use of shaftless photoelectric sensors, fundamentally eliminate the loss caused by friction, to ensure that the friction energy loss is far less than the standard requirements.
Intelligent prompt: According to the impact of the situation, intelligent prompt working status, always interact with the experimenter, to ensure the success rate of the test.
Friendly interface: there are parameter setting interface - result query interface - measurement interface - system setting interface, each operation has a clear user prompt, you can record 10 test records, you can choose domestic and international standards, you can choose Chinese and English.
Accurate measurement: In full accordance with the provisions of the new standard, after 10 swing cycles for a calculation of energy loss, each measurement to go through 3 times to average, to ensure the accuracy of energy loss.
Performance parameters
1. Simple beam impact testing machine
- Impact speed: 2.9m/s
- Impact energy: 1/2/4/5J
- Maximum friction loss energy: <0.5%
- Pendulum prelift Angle: 150±1°
- Strike center distance: 230mm
- Power supply: 220VAC-15% —— 220VAC+10%, 50Hz(single-phase three-wire system)
2. Cantilever beam impact testing machine
- Impact speed: 3.5m/s
- Impact energy: 1J; 2.75 J; 5.5 J; 11J; 22J(3 hammers, customer's choice)
- Maximum friction loss energy: <0.5%
- Pendulum prelift Angle: 150±1°
- Strike center distance: 335mm
- Power supply: 220VAC-15% —— 220VAC+10%, 50Hz(single-phase three-wire system)
Accessories
The machine typically comes with the following standard and optional accessories:
(1)Impact Hammer / Dart – Different weights or tip types for various test requirements.
(2)Specimen Clamps / Fixtures – Hold films, plastics, metals, or laminates securely in place.
(3)Base Plate / Anvil – Provides a stable impact surface; may have adjustable height.
(4)Single Chip Microcontroller & LCD Touch Screen – Main control unit for parameter setting and data display.
(5)Force / Impact Sensors – Measure impact energy, force, or displacement.
(6)Calibration Weights or Blocks – For periodic verification of sensor accuracy.
(7)Protective Safety Shield – Ensures operator safety during impact tests.
(8)Software / Data Output Interfaces – For result recording and exporting (CSV, PDF).
(9)Optional Accessories:
Different shaped impact tips (ball, cone, flat)
High-speed camera for visualizing impact
Temperature or environmental chamber for tests under special conditions
