Automotive Seat Structural Durability Test Bench | Cyclic Load Frame Strength Testing Equipment
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features
(1) Simulates vehicle collision and rapid deceleration conditions with adjustable impact speed.
(2) Impact head designed to replicate passenger head characteristics for realistic impact simulation.
(3) High measurement accuracy ensures reliable and repeatable test results.
(4) Impact arm adjustable in Z-direction and angle to accommodate various seat and headrest configurations.
(5) High-speed data acquisition system records impact velocity, acceleration, and deceleration in real time.
(6) Advanced data processing enables accurate analysis and test report generation.
(7) Robust mechanical structure ensures stable operation under repeated impact testing.
(8) Comprehensive safety protection including emergency stop and mechanical safeguards.
Parameters
| Parameter | Specification |
|---|---|
| Impact Speed | 25–30 km/h, adjustable |
| Impact Head Diameter | 165 mm |
| Equivalent Impact Mass | 6.8 kg |
| Impact Velocity Accuracy | ±1% |
| Acceleration Measurement Accuracy | ±3% |
| Impact Arm Adjustment | Adjustable in Z-direction and angle |
| Data Acquisition | High-speed recording of impact speed, acceleration, deceleration |
| Safety Protection | Emergency stop, protective net, mechanical safeguards |
Accessories
(1) Seat frame and headrest mounting fixtures.
(2) Impact head assembly.
(3) High-speed data acquisition and analysis software.
(4) Calibration tools and reference devices.
(5) Safety protection components.
Test Procedures
(1) Install the seat frame or headrest assembly securely on the test fixture.
(2) Adjust the impact arm position and angle according to the test requirement.
(3) Set the impact speed and test parameters via the control system.
(4) Perform the impact test under specified conditions.
(5) Automatically record impact velocity, acceleration, and deceleration data.
(6) Inspect the tested component for structural damage or deformation.
(7) Save and export test data and reports for analysis and documentation.
