Infusion device Leakage negative pressure tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
The tester is suitable for leakage testing of medical infusion devices in the following industries and products:
(1) Medical Quality Control: Ensures syringes, infusion sets, and other injection devices meet strict leakage standards to protect patient safety.
(2) Pharmaceutical Manufacturing: Validates packaging and device integrity for sterile medical products.
(3) Research & Development: Supports design validation, accelerated aging, and product optimization of infusion devices.
(4) Certification & Regulatory Testing: Enables compliance with national and international medical device standards and regulatory requirements.
(5) Third-Party Testing Laboratories: Provides standardized, repeatable leakage testing for medical device certification.
Standards
The instrument is compliant with the following standards, including relevant international regulations:
(1) GB 8368-2005 – Disposable Infusion Sets for Single Use — Gravity Infusion Type, Airtightness Testing Requirements
(2) ISO 8536-4 – Sterile Syringes for Medical Use — Leakage Test Methods
(3) ISO 13485:2016 – Medical Devices — Quality Management Systems for Regulatory Compliance
(4) ASTM F2392-04 – Guide for Leak Testing of Medical Fluid Delivery Devices
Features
(1) Precision negative pressure testing: -10 to -30 kPa with ±0.5 kPa accuracy
(2) Dual-temperature testing: 23 ±1°C and 40 ±1°C to simulate real-world and accelerated aging conditions
(3) PLC-driven automated control: ensures repeatable and reliable results
(4) Safety interlocks and auto-shutoff prevent device damage
(5) Compact footprint (500×600×500 mm) suitable for labs and production lines
(6) Adjustable test time (1–16 seconds) with intuitive digital touchscreen interface
(7) Distilled water flushing system in vacuum chamber eliminates air bubbles for accurate detection
(8) Stainless steel construction for corrosion resistance and easy cleaning
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Mode | Automatic (PLC) |
| Test Pressure Range | -10 kPa to -30 kPa (Adjustable) |
| Pressure Accuracy | ±0.5 kPa |
| Temperature Range | 23 ±1°C / 40 ±1°C |
| Test Time | 1–16 seconds (Adjustable) |
| Chamber Material | Medical-grade stainless steel |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 500 mm × 600 mm × 500 mm |
| Net Weight | 30 kg |
| Display | LED Touchscreen (Pressure/Time/Status) |
Accessories
(1) Vacuum chamber with integrated distilled water flushing system
(2) Standard connectors for syringes and infusion sets
(3) Power cable
(4) Operation manual
(5) Calibration certificate
