Bone Screw Static Torque Testing Machine

Bone Screw Static Torque Testing Machine
  • Bone Screw Static Torque Testing Machine
Производитель: Шанхайская компания Qianshi Precision Electromechanical Technology Co., Ltd

Все товары поставщика
Отправить запрос, связаться с поставщиком

Standard

  • YY/T 0591-2011: Chinese standard specifying torsion testing methods for intramedullary nails, including torque application, angular displacement measurement, and failure criteria.
  • ASTM F1264: International standard covering mechanical testing of intramedullary fixation devices, with protocols for static and quasi-static torsion tests.

Product Advantages

  1. Precision Torsional Control:
    • Electromagnetic servo-controlled torsion system ensures torque application with ±0.1% accuracy, adhering to ASTM F1264’s resolution requirements.
    • Adjustable torque range (0.1–500 Nm) and rotational speed (0.01°–360°/min) for versatile testing scenarios.
  2. Customized Fixturing:
    • Modular torsion clamps with interchangeable collets (6–16mm diameter) and anti-slip mechanisms to accommodate diverse nail diameters and lengths.
    • Specimen alignment guides ensure consistent angular displacement measurements.
  3. Advanced Data Acquisition:
    • Real-time monitoring of torque, angular displacement, and shear modulus with 5000Hz sampling rate.
    • Automatic calculation of key parameters: torsional rigidity (Nm/°), yield torque (Nm), and failure angle (°).
  4. User-Centric Design:
    • Intuitive software with preloaded SOPs for YY/T 0591 and ASTM F1264 compliance.
    • Multi-language interface (English/Chinese/Spanish) and exportable reports (PDF/Excel/CSV).
  5. Durability & Safety:
    • Corrosion-resistant steel frame and overload protection system for long-term reliability.
    • Low-noise operation (<65 dB) suitable for laboratory environments.

Product Features

  • Torque Capacity: 0.1–500 Nm (torsional).
  • Torque Resolution: 0.001 Nm.
  • Angular Accuracy: ±0.01°.
  • Testing Modes:
    • Torsional rigidity (ASTM F1264).
    • Yield torque and failure angle (YY/T 0591).
    • Load-deflection curve analysis.
  • Software Suite:
    • Customizable test profiles with automated pass/fail criteria.
    • 21 CFR Part 11 compliance for audit trails and electronic signatures.
  • Calibration: NIST-traceable certification included, with annual recalibration available.

Technical Parameters

ParameterSpecification
Torque Range 0.1–500 Nm (torsional)
Angular Resolution 0.001°
Rotational Speed 0.01°–360°/min
Power Supply 220V/110V, 50/60Hz
Dimensions (W×D×H) 600×500×1,600 mm
Weight 250 kg
Compliance CE, ISO 13485, YY/T 0591, ASTM F1264

Accessories (Included/Optional)

  • Standard Kit:
    • Torsion clamps (6mm, 10mm, 16mm collets).
    • Calibration weights and torque wrench.
    • Test control software with preloaded SOPs.
  • Optional Upgrades:
    • Axial-torsional load frame (for combined loading tests).
    • Environmental chamber (for thermal cycling tests).
    • Custom fixturing for pediatric/specialized intramedullary nails.
    • Remote diagnostics and preventive maintenance package.
