Helmet Surface Friction Testing Machine/ Helmet surface friction tester
Все товары поставщика
The Helmet Surface Friction Testing Machine
In the critical realm of head protection, a helmet's primary role is to absorb and deflect impact forces. However, an often-overlooked yet vital aspect of helmet safety is its surface friction – how it interacts with external surfaces during an oblique or glancing impact. High friction can cause a helmet to "stick" and transmit rotational forces directly to the head and neck, potentially leading to severe brain injuries. This is precisely why the Helmet Surface Friction Testing Machine is an indispensable tool for advancing helmet safety.
Purpose
The Helmet Surface Friction Tester presses a helmet onto a movable fixture with a certain force. The surface of the fixture is attached with sandpaper of the grain size specified in the standard. Then, the test helmet is moved across the surface of the sandpaper at a certain speed, so as to evaluate the abrasion - resistance performance of the helmet.
Applicable standards
GB 811-2022
Main features
1、PLC touch screen control
2、Horizontally oriented carrier with exchangeable mounting of sandpaper and cutting knives
3、Head type can be rotated 360
4、With professional speed measuring tooling
Technical Parameters
1. friction sandpaper: 300mm-303mm long, grade 80 aluminum oxide coated sandpaper.
2. steel cutter: 6mm high, 25mm wide, the top edge of the cutter is chamfered with a radius of 1mm.
3. impact weights: 15kg-15.5kg
4、Fall height of the weight: 0-1000mm
5、Pre-loaded weight: 400N-410N
6、Sensor range：0-120mm
7. instrument power supply: 220V 50HZ
