Industrial Oven for Batteries
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1.Real-time temperature monitoring, temperature range can be customized to +1000 ° C, +1200 ° C, accuracy ±0.5 ° C, uniform distribution ±2%.
2.The programmable PID control system supports multi-stage temperature curves for complex loop testing.
3.The enhanced thermal efficiency reduces heating time and minimizes energy consumption.
4.Flexibleworkroomsize and adjustable sample holder to accommodate various battery types and component sizes.
5.High temperature performance testing, thermal aging and durability assessment, safety certification testing, material compatibility analysis.
Specifications
Model |
STD O-100 |
STD O-225 |
STD O-500 |
STD O-800 |
STD O-1000 |
Internal Dimension (mm) |
400*500*500 |
500*600*750 |
700*800*900 |
800*1000*1000 |
1000*1000*1000 |
Overall Dimension (mm) |
750*880*850 |
800*950*1000 |
1100*1100*1300 |
1100*1450*1400 |
1300*1400*1400 |
Interior Volume |
100L |
225L |
500L |
800L |
1000L |
Temperature Range |
A: Ambient～+250 ℃ B: Ambient～+400 ℃ C: Ambient～+900 ℃ |
||||
Temperature Fluctuation |
± 0.5 ℃ |
||||
Temperature Deviation |
± 2.0 ℃ |
||||
Heating Rate |
6 ℃ / min |
||||
Heating Element |
Nichrome heater |
||||
Controller |
Programmable color LCD touch screen controller, Ethernet connection |
||||
Safety Device |
Over-temperature Protection; Over-current Protection; Phase Sequence Protection; Earth leakage Protection |
||||
Exterior Material |
Steel Plate with protective coating |
||||
Interior Material |
SUS304 stainless steel |
||||
Thermal Insulation |
Polyurethane foam（Refractory brick） |
||||
Observation Window |
Interior lighting, double-layer thermo stability silicone rubber sealing |
||||
Standard Configuration |
2 shelves |
||||
