Paper stiffness meter
Все товары поставщика
Paper stiffness meter - Other test instrument - standard
Product Introduction:
ZY-TDY300 microcomputer bending stiffness tester is used to measure the bending stiffness of paper and cardboard materials with low gram weight. It is used to evaluate the stiffness and resilience of flexible materials. It can set the vertical and horizontal direction, tension size, test speed and bending Angle of the sample according to the test requirements. Mainly used to measure all kinds of paper, cardboard, film, plastic, wire, metal sheet and other composite materials bending stiffness test, the measurement range is :0——1000g（0——10000mN） suitable for paper packaging printing industry and related scientific research institutions and quality inspection departments.
Technical parameters:
1. Sample size :38*（70——200）mm
2. Actual measurement size :38*（1——50）mm
3. Test spacing :1mm, 5mm, 10mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm
4. Span accuracy :±0.1mm
5. Measuring range :0——1000g（0——10000mN） can be customized
6. Sensor: The sensing accuracy is 0.1%
7. Resolution :0.01mN
8. Bending Angle :1——95° no pole adjustable
9. Multi-functional measurement: stiffness/folding Wolf stiffness dual system
10. Angular speed control :0.5——5°/sec adjustable
11. Angle accuracy :±0.1°
12. Measure the maximum thickness :（0.01——5.0）mm
13. Bending time :（2——50s）
14. Operation interface :7inch touch screen or button test
15. Signal output: Standard computer signal output, link computer （optional）
16. Print output: modular integrated thermal printer
17. Dimensions :320mm*320mm*300mm
18. Net weight :28kg
