Horizontal paper tensile strength testing machine - Other test instrument - standard
Product Introduction:
G103C horizontal tensile strength tester adopts paper tensile strength software, which is a paper resistance tester for measuring the tensile strength, tensile strength and tensile energy absorption of paper and cardboard, paper towels, wipes and other similar thin sheet materials. Suitable for all kinds of paper, electrolytic aluminum, release paper, release film, isolation paper, Glassine silicone oil paper, protective film, transfer film, composite film, tape, adhesive and other products （measuring tensile strength, peeling force, tensile strength, peeling strength, elongation, breaking length, tensile energy absorption, tensile index, tensile energy absorption index） high-precision test.
Implementation standards:
ISO 1924 "Determination of tensile strength of paper and board"
GB/T 12914 "Determination of tensile strength of paper and board （constant rate tensile method）"
ISO 1924-2 Paper and board - Determination of tensile strength - Part 2: Constant rate drawing method
Technical parameters:
Load measurement range: 0.03-30N, 0.05-50N, 0.2-100N, 0.4-200N, 0.5-300N
Force separation rate: 0.001N
Displacement separation rate: 0.001mm
Loading speed: 1-500mm/min（other speed is adjustable）
Sample width: 0-30mm
Travel: 400mm+
Power: 60W
Power supply: 220V 50Hz
Dimensions: 280mm×150mm×800mm （approx.）
Environmental requirements: Temperature 10-35 ℃， humidity 20-80%
