Standards:

SNELL SA/K2010, EN 166, EN 168, ANSI Z87.1, MIL - PRF - 32432

Applications:

To test the impact - resistance performance of glasses, goggles and face shields at a certain speed.

Product Information:

Technical Parameters

1. High - speed speed - measuring system, adopting high - precision laser speed - measuring and sensing device. 2. Equipped with safety warning lights. When the equipment door is not properly closed, the equipment cannot enter the testing state (dual - limit switches are installed at the position of the door handle). 3. Touch - screen control. The speed units that the equipment can display include ft/s, m/s, km/s. 4. Head mold material: Silicone, simulating the human head shape (with ears, nose and mouth). 5. Air source requirements for the air compressor: Flow rate ≥ 500l/min, air pressure ≥ 0.65Apa. 6. Power supply: AC 220V 50HZ. 7. The control panel is equipped with an emergency stop device for higher safety; a digital LCD display shows the speed (m/s) of the ejected object.
