Fabric Drying Tester

Product Introduction:

This device is developed for the automatic test of "dryness" method A and method B specified in JIS L 1096 (Fabric test method for fabrics and woven fabrics)。 Previously, the test of method A took a lot of time and was very troublesome. By automating it, only the sample cloth could be suspended on the device to automatically measure 3 samples at the same time, and the measurement data could be stored on the computer at any time. In addition, if the test time setting mode or dry recognition mode is set, the device will automatically stop when the selected mode is over, and the test end alarm sound will be issued. Each piece of data is saved in a data file, and the data can be viewed or edited on other computers. The automatic cloth dryness measuring device not only measures the well-known "dryness after washing", but also tests how long the sweat evaporates and disperses after penetrating the fabric and woven fabric, and is widely used. It is also used in the research and development of materials with the aim of retaining water and moisturizing properties, as opposed to "quick drying properties."

Standard：

AATCC 201

Features:

1. In a fully automatic device, just hang the sample cloth for fully automatic measurement.

2. Can measure 3 samples at the same time.

3. Each measurement data is displayed on the monitor with graphics or numerical values, and printed by color printer.

4. You can choose the test time, set the mode and dry recognition mode.

5. It can be controlled and processed by computer Window.

Equipment composition:

1. Measuring department and 1 automatic sample moving equipment

2. Control/data processing equipment (Windows)， 1 color printer

Data display content:

(1) Method A or Method B

(2)Method A

The measured value represents sample No. (1-3)， elapsed time, weight, time setting mode or drying recognition mode, etc

The chart shows sample No. (1 —— 3)， X-axis/elapsed time, Y-axis/weight change, etc

Method B

The measured value represents the cloth weight of sample No. (1 —— 3) before water absorption, the cloth weight of sample 10 minutes after water absorption, and the average moisture weight of sample No. 1-3

Specification parameters:

Model: IT-ACD, IT-ACDS (Special for measuring trace moisture)

Sample size: 1——3 (the number can be changed according to demand)

Test standard: JIS L1096 (Fabric and woven fabric test method) dryness and evaporation A method, B method

Weighing and minimum sensitivity (including air bag weight) : 2000 g/ 0.01 g (10mg) 600g/ 0.001g (1mg)

Test interval: 5min/ sample

Sample fabric size: 40x40cm for method A and 15x15cm for method B

Automatic mode: Time setting mode 1 —— 48 hours (arbitrarily set in 1 hour)

Drying recognition Mode IT-ACD 50mg, 100-1000mg (set to 100mg unit)

IT-ACDS 1Mg-10mg (set in 1mg unit)

15mg, 20mg - 100mg (in 10mg units)

Control and data processing devices: Windows

Recording method: color printer

Options: Special windshield (front part transparent acrylic door open and closed, top/sides/back non-wove

Другие товары поставщика

	Environmental Stress Cracking Resistance Tester / ESCR Tester	Standard ASTM D1693: Exclusively designed for bending beam and constant load tests on polyethylene and other thermoplastics. ISO 22088-3: Configu...
	SI80 Carbon Arc Aging Tester | Professional xenon arc aging test chamber	Material aging and fading performance test SI80 carbon arc aging tester, carbon arc aging machine through AC light carbon rod, produce arc light, ...
	Multilayer geotextile single-layer thickness tester丨IS0 9863	Meet the standard GB/T17598-1998. GB/T 13761.1-2022. JTG E50-2006. IS09863-90 Scope of application The multi-layer sample is mechanically separa...
	RIDER Method Single Fiber Friction Tester	Meet the standard: JIS L1015 (Chemical fiber binding test method)， JIS L 1095 (General yarn test method)/friction coefficient Purpose: This inst...
	Catheter Burst Pressure Tester / Catheter Burst Pressure Testing Equipment	Compliance Standards YY/T 1536 - 2017 YY 0285.1 - 2017. etc. Main Uses The catheter burst pressure tester is a key device used to evaluate cathe...
