Full Notch Creep Tester

Standard

ISO 16770: Exclusively designed for full-notch creep testing (FNCT) of thermoplastics under sustained stress.

ASTM D2990: Configurable for tensile, compressive, and flexural creep testing of polymers and composites.

ISO899

ISO3501

Product Advantages

1. Uncompromising Precision

Independent 6-Zone Control: Each station operates with ±1% force accuracy (0–2.000N) and ±0.1°C temperature stability.

Hybrid Loading System: Combines motorized force application with manual fine-tuning via touchscreen-guided weights.

2. Versatile Testing Environments

Dual Bath Compatibility: Switch between water (up to 95°C) and oil (up to 150°C) baths for high-temperature polymer analysis.

Expanded Force Capacity: Upgradeable to 4.000N max. load per station for heavy-duty applications.

3. Intelligent Monitoring

Auto-Level Sensing: Real-time solution height detection prevents test interruptions from evaporation or leaks.

Visual Alerts: Touchscreen displays color-coded status indicators for all stations.

4. Future-Ready Design

Modular Architecture: Add stations or upgrade controllers without replacing the entire system.

Multi-Language Interface: Operate in English, German, Chinese, or Spanish.

Product Features

Precision Actuation:

Servo-hydraulic loading with 0.001mm/min creep resolution.

Manual override mode for delicate sample alignment.

Advanced Thermal Management:

Independent PID-controlled heating elements per station.

Magnetic stirrers ensure uniform bath temperature (±0.2°C).

Data Integrity:

100Hz sampling rate captures transient creep events.

AES-256 encrypted data logging with timestamped audit trails.

Ease of Use:

10.4” industrial touchscreen with gesture control.

Pre-loaded ISO 16770 test protocols with customizable hold times.

Accessories & Options

Test Media:

High-temperature silicone oil (150°C max.)

Deionized water reservoir with auto-refill.

Sample Fixtures:

Self-tightening grips for notched specimens (ISO 16770 compliant).

Flat dog-bone clamps for ASTM D2990 testing.

Software Bundle:

CreepVision Pro™: AI-assisted strain analysis with Weibull modulus calculation.

LabShare Cloud: Remote monitoring for up to 50 concurrent users.

Calibration Kit:

NIST-traceable force gauge and thermocouple set.

Extended Warranty:

5-year comprehensive coverage for load cells and controllers.

Technical Parameters

Specification	Details
Stations	6 fully independent test positions
Force Range (per station)	0–2.000N (standard) / 0–4.000N (optional)
Temperature Control	Water: 40–95°C
Force Accuracy	±1% FS (0.5% with calibration kit)
Power Supply	220V/50Hz (110V/60Hz available)
Bath Capacity	15L per station (90L total)
Dimensions (W×D×H)	1.800mm × 750mm × 1.650mm
Weight	380 kg (net)
