Bone Screw Static Torque Testing Machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
YY/T 0591-2011: Chinese standard specifying torsion testing methods for intramedullary nails, including torque application, angular displacement measurement, and failure criteria.
ASTM F1264: International standard covering mechanical testing of intramedullary fixation devices, with protocols for static and quasi-static torsion tests.
Product Advantages
Precision Torsional Control:
Electromagnetic servo-controlled torsion system ensures torque application with ±0.1% accuracy, adhering to ASTM F1264’s resolution requirements.
Adjustable torque range (0.1–500 Nm) and rotational speed (0.01°–360°/min) for versatile testing scenarios.
Customized Fixturing:
Modular torsion clamps with interchangeable collets (6–16mm diameter) and anti-slip mechanisms to accommodate diverse nail diameters and lengths.
Specimen alignment guides ensure consistent angular displacement measurements.
Advanced Data Acquisition:
Real-time monitoring of torque, angular displacement, and shear modulus with 5000Hz sampling rate.
Automatic calculation of key parameters: torsional rigidity (Nm/°), yield torque (Nm), and failure angle (°).
User-Centric Design:
Intuitive software with preloaded SOPs for YY/T 0591 and ASTM F1264 compliance.
Multi-language interface (English/Chinese/Spanish) and exportable reports (PDF/Excel/CSV).
Durability & Safety:
Corrosion-resistant steel frame and overload protection system for long-term reliability.
Low-noise operation (
Product Features
Torque Capacity: 0.1–500 Nm (torsional).
Torque Resolution: 0.001 Nm.
Angular Accuracy: ±0.01°.
Testing Modes:
Torsional rigidity (ASTM F1264).
Yield torque and failure angle (YY/T 0591).
Load-deflection curve analysis.
Software Suite:
Customizable test profiles with automated pass/fail criteria.
21 CFR Part 11 compliance for audit trails and electronic signatures.
Calibration: NIST-traceable certification included, with annual recalibration available.
Technical Parameters
| Parameter | Specification |
|---|---|
| Torque Range | 0.1–500 Nm (torsional) |
| Angular Resolution | 0.001° |
| Rotational Speed | 0.01°–360°/min |
| Power Supply | 220V/110V, 50/60Hz |
| Dimensions (W×D×H) | 600×500×1.600 mm |
| Weight | 250 kg |
| Compliance | CE, ISO 13485. YY/T 0591. ASTM F1264 |
Accessories (Included/Optional)
Standard Kit:
Torsion clamps (6mm, 10mm, 16mm collets).
Calibration weights and torque wrench.
Test control software with preloaded SOPs.
Optional Upgrades:
Axial-torsional load frame (for combined loading tests).
Environmental chamber (for thermal cycling tests).
Custom fixturing for pediatric/specialized intramedullary nails.
Remote diagnostics and preventive maintenance package.
