Particle Strength Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
- ASTM D4179: Standard Test Method for Single-Pellet Pressure Resistance of Catalysts and Catalyst Carriers
- ASTM D6175: Standard Test Method for Radial Crush Strength of Extruded Catalyst and Catalyst Carrier Particles
- ISO 9773: Methods for Testing Catalysts – Radial Crush Strength
Product Advantages
- Unrivaled Precision
- Sub-micron Force Resolution: Detects forces as low as 0.001 N for fragile materials like pharmaceutical granules.
- High-Speed Data Acquisition: 10,000 Hz sampling rate captures transient deformation events.
- Universal Applicability
- Tests particles from 0.1 mm to 50 mm in diameter (spherical, cylindrical, irregular shapes).
- Multi-Mode Testing: Compression, tension, shear, and indentation modes in one platform.
- Intelligent Automation
- AI-powered load application adjusts speed and force in real-time to prevent sample damage.
- Auto-Centering Fixture: Ensures perfect alignment for irregularly shaped particles.
- User-Friendly Workflow
- 10.1” HD touchscreen with gesture control and multilingual interface (12 languages).
- One-Click Testing: Preprogrammed protocols for ASTM/ISO standards simplify operator training.
- Data Integrity
- Blockchain-secured data storage prevents tampering (compatible with 21 CFR Part 11).
- Cloud-connected analytics for remote monitoring and collaboration.
Product Features
- Non-Destructive Testing (NDT) Option: Ultrasonic imaging module visualizes internal cracks without breaking samples.
- Environmental Chamber Compatibility: Temperature (-40°C to 200°C) and humidity (10%–95% RH) control.
- Dynamic Force Profiling: Programmable force ramps with sinusoidal, triangular, or custom waveforms.
- 3D Force Mapping: Scans particle surfaces to identify weak points before full testing.
- Emergency Stop System: Laser-based safety curtain halts operation upon intrusion detection.
Technical Parameters
| Parameter | Specification |
|---|
| Force Range |
0.001 N – 5,000 N (500 kgf) |
| Force Accuracy |
±0.1% of reading (1–5,000 N) |
| Displacement Resolution |
0.01 μm |
| Testing Speed |
0.001–1,000 mm/min (adjustable) |
| Return Speed |
Up to 2,000 mm/min for rapid cycling |
| Connectivity |
USB 3.1, Ethernet, Wi-Fi 6, Bluetooth 5.0 |
| Power Consumption |
600 W (max), 50 W (idle) |
| Dimensions |
550mm (W) × 480mm (D) × 720mm (H) |
| Weight |
75 kg (net) / 90 kg (gross) |
Accessories Included
- Testing Fixture Kit:
- Compression platens (2mm/5mm/10mm diameters).
- Tensile grips with serrated jaws (0.5–50mm capacity).
- Shear blade set (V-notch and flat options).
- Software Suite:
- License key forParticleAnalyst Pro(Windows/macOS).
- 6-month free access to AI-driven failure prediction module.
- Calibration & Safety:
- NIST-traceable calibration weights (1g–500g set).
- Emergency stop pendant with magnetic dock.
- Portability & Storage:
- Shockproof carrying case with custom foam inserts.
- Dust cover and anti-vibration pads.
- Documentation:
- Quick-start guide (printed and digital).
- Compliance certificates for ASTM/ISO standards.
