3.5inch Embedded Motherboard AIoT3-EHL12
JWIPC AIoT3-EHL industrial motherboard mainly uses Intel Elkhart Lake series processors, supports DDR4 SO-DIMM memory slots, adopts a 3.5 inch single board computercompact design, supports HDMI+DP 4K dual independent display output, and matches the processor's powerful computing functions and industrial Features, this intel embedded motherboardis suitable for industrial automation, medical, machine vision, IoT edge and other applications.
Intel J6412/J6413/N6211
DDR4 SO-DIMM, Max 32GB
HDMI+DP display
Dual RJ45 2.5Gb Ethernet
4 x COM (RS232/RS485)
SPECIFICATION OF 3.5INCH EMBEDDED MOTHERBOARD AIOT3-EHL12
Product
Model
AIoT9-H110
Type
Micro ATX Industrial Motherboards
Processor
Chipset
Intel® H110 Chipset, Option C236 for E3 V5&V6
CPU
Support Intel LGA1151 Gen.6/7/8/9th i3/i5/i7/i9/Pentium/Celeron CPU
Memory
Socket
H110 support 2×288Pin DDR4, C236 support 4 ×288Pin DDR4 DIMM up to 64GB
Graphics
Controller
Intel HD Graphics (Depends the CPU)
Display
Supports Triple display of DVI-D+VGA+HDMI, C236 support Independent triple display
Storage
Type
H110 support SATA, C236 support 5 SATA3.0 port Support SATA Raid 0/1/5/10
1 M.2 2280 (SATA3.0 bus) SSD
Network
Ethernet
Dual intel GbE Ethernet ports, LAN1: Intel I219LM, LAN2: Intel I211AT
I/O
TPMInterface
Support 1 x TPM interface, extensible TPM module
Audio
Support Mic-in, Speaker-out
USB
4 USB3.0 Type A Rear I/O, 2 USB3.0 pin header inside
2 USB2.0 pin header inside for front I/O (C236 support 6 USB2.0)
LPT
1 x LPT port
COM
6 COM (Scalable 10 COM), COM1 support RS232/422/485, COM2-6 support RS232
KB/MouseConnector
1×PS/2 2 in 1 Connector & 2 x USB 3 in 1 Connector
DigitalI/O
8-bit Digital I/O
LPCInterface
Support 2 x 6 Pin LPC bus, extensible COM module, etc.
Power
Input
ATX power supply, support ATX/AT mode
Expansion
Interface
1 x PCIe x16, 1 x PCIe x4 slot
2 x PCI slot (32bit)
1 x M.2 2280 Slot support SATA SSD
Environment
Temperature
Operating: 0~60℃, Storage: -40~80℃
Humidity
5% to 95%, Non-condensing
System
BIOS
AMI UEFI BIOS
OperatingSystem
Win7/Win10/WES7/Linux, 32bit/64bit
Function
WatchDog
Software programmable 1~255 second/minute system interrupt/reset
PCB
Color
Industry green
Dimensions
244mm X 244mm
HIGHLIGHTS OF 3.5INCH EMBEDDED MOTHERBOARD AIOT3-EHL12
The AIoT3-EHL industrial motherboard has a variety of network transmission methods. Dual RJ45 2.5Gb Ethernet, M.2 4G/5G modules, meet the needs of low-latency network data transmission. The AIoT3-EHL series supports a wealth of expansion interfaces. The four RS232/RS485 serial ports can be expanded to 6 or 10 serial ports to suit different scenarios. Half-length Wifi+BT; supports 16-bit digital I/O with optocoupler isolation and supports up to four gigabit switching network interfaces.
The motherboard adopts high Tg and wide temperature PCB material to ensure wide temperature stability; industrial-grade port protection blocks static electricity and surges, effectively protecting the stability and safety of the system core. The device supports watchdog, supports wide temperature operation, and improves system reliability. A safe choice for portable equipment and industrial applications.
ORDERING INFORMATION OF 3.5INCH EMBEDDED MOTHERBOARD AIOT3-EHL12
|
Model |
LAN |
USB3 |
USB2 |
COM |
SSD |
NET |
|
|
AIoT3-EHL13-2G |
J6413 |
2 x 2.5GbE |
3 |
3 |
4 |
4G/5G |
|
|
AIoT3-EHL13-1G |
J6413 |
2 x 1GbE |
3 |
3 |
4 |
4G/5G |
|
|
AIoT3-EHL11-1G |
N6211 |
2 x 1GbE |
3 |
3 |
4 |
4G/5G |
|
|
AIoT3-EHL12 |
J6412 |
2 x 2.5GbE |
3 |
3 |
4 |
4G/5G |
As one of internet of things hardware companies, we have types of iot hardwarefor sale, if you have needs, please contact us.
