COLORTHERM Green GN-M

Description

Type: Green Pigment, Micronized

Delivery Form: Powder

Chemical Grade: Chromium Oxide (Cr2O3)

Color Index: Pigment Green 17 (77288)

CAS No: 1308-38-9

REACH Registration Number:

Technical Data

Color value and tinting strength
Standard sample COLORTHERM Green GN-M
Years 2009
Resin: Full color Diluted45 Test method
Test paste based on a non-drying alkyd resin Use titanium dioxide (1:5) No 00141
Minimum value Maximum value Minimum value Maximum value
△L* -0.5 0.5
△a* -0.6 0.6 -0.6 0.6
△b* -0.6 0.6 -0.6 0.6
△C*ab -0.8 0.8 -0.8 0.8
△H*ab -0.8 0.8 -0.8 0.8
△E*ab 1.0 1.0
Relative tinting strength[%] 95 105
Dispersibility Maximum value Test method
Grinding Fineness[µm] 10/15/50 PVS 107 41
Technical Data Minimum value Maximum value
Water-Soluble Salts [%] 0.3 DINENISO787-3:2000
Water-Soluble Hexavalent Chromium [ppm] 5 PVS10341
Sieve Residue (0.045 mm Sieve) [%] 0.005 DINENISO787-7:2009
pH 5.0 7.0 DINENISO787-9:1995
Test method
Cr2O3content [%] ~ 99 X-ray fluorescence spectroscopy
Loss at 1000°C, 0.25 h [%] ~ 0.4 DIN ISO 4621:1988
Particle shape Spherical Electron micrograph
Main particle size [µm] ~ 0.3 Electron micrograph
Oil absorption [g/100 g] ~ 11 DIN EN ISO 787-5:1995
Tamp density [g/ml] 0.8-1.2 DIN EN ISO 787-11:1995
Thermal stability [°C] 300 DIN EN 12877-2:1999
Density [g/ml] ~ 5.2 DIN EN ISO 787-10:1995
