Instrument powder Coating
Introduction
It is made of polyester resin and epoxy resin as the main base materials, and has the excellent decorative, mechanical properties and good corrosion resistance of epoxy and polyester.
| Location | China |
| Business Type | Manufacturer, Exporter |
| Brand | Standard |
| Certificate | ACS,NSF,QUALICAOT,WRAS,KTW |
| Payment and Delivery Terms | 30% advance payment, 70% before delivery |
| Minimum Order Quantity | 100kg |
| Price | Negotiable |
| Delivery Time | 7-10 days |
| Payment Method | T/T,L/C |
Brief Description
This product is made of polyester resin and epoxy resin as the main base materials, combining the excellent decorative properties, mechanical properties and good corrosion resistance of epoxy and polyester.
Features
Excellent mechanical properties (impact resistance, hardness, toughness, adhesion, etc.)
Good leveling and gloss
Strong corrosion resistance
Application areas
Household appliances, communication equipment units, indoor fitness equipment, tool boxes, filing cabinets, shelves, lamps, etc.
Product series
Standard curing type and low temperature curing type are available
Various gloss and colors can be made
Various texture products such as flat surface, art texture, metal effect, antique can be made
Technical parameters
Mechanical properties
| Test items | Test standards | Performance indicators |
|---|---|---|
| Pencil hardness | GB/T6739-1996 | >H |
| Adhesion | GB/T9286-1998 | Grade 0 |
| Bending | GB6742-86 | 3mm |
| Impact | GB/T1732-93 | 50kg.cm |
| Cupping | GB9753-88 | >6mm |
Corrosion resistance
| Test items | Test standards | Performance indicators |
|---|---|---|
| Salt spray resistance | GB/T1771-91 | No change in coating after 500 hours, single-side isolation at specification <2mm |
| Moisture and heat resistance | GB/T1740-79 | >500 hours slight gloss loss, ≤Grade 1 |
Note: The above parameters are laboratory data for reference only. Actual indicators are related to factors such as customer environment, equipment, materials, pretreatment, and spraying process.
Powder performance
Specific gravity: 1.1~1.8g/cm³
Application conditions
Pretreatment: phosphating, chromating
Coating: Suitable for high-voltage electrostatic spraying, friction electrostatic spraying, electrostatic fluidized bed spraying, fluidized bed dipping
Curing conditions:
140℃ at 30 minutes
180℃ at 15 minutes
200℃ at 10 Minutes
Can also be designed according to customer needs
Packaging
Carton packaging
Net weight 20kg/box
Lined with polyethylene plastic bag
Storage conditions
Store in a dry, ventilated room below 30°C
Avoid direct sunlight
Under this condition, the powder can be stably stored for 6 months
Safety and health
- All raw materials of powder coatings do not contain toxic substances.
- No toxic gas is released during baking.
- Avoid inhalation of dust during use.
- Operators should wear dust masks.
- Minimize long-term contact between skin and powder.
- Paint attached to the skin can be washed with soap.
If you're ready to take the next step or Request Free Samples, Leave your message below and we’ll reply soon. 20+ years of chemical manufacturing & export experience, a partner you can trust.
