Single Layer Ceramic PCB
Single Layer Ceramic PCBPartnumber: FASTPCBA-029Specs:Size: 80MM*96MMMin hole size: 0.5mmSurface finishing: Immersion gold( ENIG)Min hole trace and space: 6mil/6milSolder mask: White solder mask LPISilkscreen: YellowApplication: High frequency device bare PCB,Website:, communication board, wireless electronics.Certificate: TS16949:2002, UL, ROHS, CEQuality standard: IPC-CLASSIIFlaming rate: 94V0 PCBProduction capability: 20000sqm/monthMaterial: Rogers R4350B, 0.8mm thickness.Packing: VCCCompany profile:FASTPCBA Technology Co., Ltd is a professional PCB manufacturer in China, Shenzhen. With 14 years of delelopment, FASPCBA turns into a first class manufacturer of HDI PCB, with production capability 35,000 square meters. FASTPCBA is providing high quality bare PCB and PCB assembly service, including components sourcing, function test, conformal coating and complete assembly for clients all over the world, our main market is Europe, north USA, Australia, South America, and Asia.Products Involved Fields:Consumming Electronics, Medical Equipments, Industrial commands, Communications, Auto Parts, Military PCB, Solar Inverter PCB etc.PCB Capability Parameter:ItemMass processingcapabilitySample&PrototypeProcessing capabilityLayer(MAX)2-1820-30Type of the board materialFR-4,high TG Board,aluminumboard rogers, etc.,F4,BTFR4,high TG Board,aluminumboard Rogers,etc.,F4,BTCompound pressed board4layers--6layers6layers--8layersMaximum Size610mm*1100mmOutline size tolerance+/- 0.13mm+/- 0.10mmBoard Thickness range0.3mm-6.00mm0.20mm--8.00mmBoard Thickness tolerance+/- 8%+/- 5%Board Thickness Range+/- 10%+/- 8%Medium Thickness0.076mm-6.000.076mm--0.100mmMinimum line width0.075mm0.063mmMinimum space Distance0.075mm0.063mmOuter layer copper thickness8.75um--175um8.75um--280umInner Layer copper thickness8.75um--175um8.75um--220umDrill hole size(power drill)0.25mm--6mm0.15mm--0.25mmHole size(power drill)0.20mm--6mm0.05mm--0.20mmHole size tolerance(power drill)0.05mmHole position deviation(power drill)0.075mm0.05mmLaser hole size0.10mm0.075mmAspect Ratio10:112:1Solder mask typeSensitive green,yellow.Black,purple,blue,inkSensitive green,yellow.Black,purple,blue,inkMininum width of soldermask bridge0.10mm0.075mmMinimum size of solder maskSeparation ring0.05mm0.025mmSurface Finish: HAL,ENIG.Plating nickel, thick&hard/soft metal,chemical nickel,Lead free, tin immersion ead free H.A.S.L Entek gold-finger,Immersion Tin,OSP and selective surface processing .Strict Quality System: Our motto is qualiy;efficiency and competitive price.we strictly adhere to the TS14969 standards, and continuosly apply advanced international technology to improve the quality of the product to meet needs of our customers.One-stop PCB assembly service, We can offer 1 to 22 Layer PCB fabrication, PCB design, PCB layout, PCB manufacturing, PCB Assemblies, components sourcing, PCBA Function Test, design solution.RELIABILITY TESTS100% Electrical Test100% Visual Inspection (including warp & twist check)Dimensional Inspection (finished hole sizes, pcb profiles, etc)Micro sectionSolder ability Test (245±5ºC; 3-5 sec)Thermal Test (288±5ºC; 10 sec. inspect delamination, etc)Tape Test (adhesion test)Peel Test (conductor peel strength)Impedance TestAOI testingVirtual function testOther Ceramic PCB we produced: Our service: 1. To be a highly reliant OEM service provider2. To create a better life for our staff.3. To satisfy our partners with good quality and fast deliveryFactory:
