Coated fabric flexing resistance testing machine

Instrument Purpose

The instrument tests coated fabric strips by winding them into cylindrical samples between two rotating cylinders. One cylinder reciprocates along its axis to alternately compress and relax the fabric tube, creating folds until predetermined cycles are completed or sample failure occurs.

Compliance Standards

ISO 7854,GB/T 12586-B,BS 3424:9

Product Features

  • Precise motor control system for disc rotation and movement
  • Reliable cam-driven mechanism ensures stability
  • Imported precision guide rails for durability

Technical Specifications

Clamps 6 sets
Rotation Speed 8.3Hz±0.4Hz (498±24 rpm)
Cylinders Outer diameter 25.4±0.1mm
Test Path
Stroke 11.7±0.35mm
Clamp Width 10±1mm
Clamp Distance 36±1mm
Sample Size 50×105mm
Dimensions 40×55×35cm
Weight ≈65kg
Power 220V 50Hz

Configuration List

  • 1 host unit
  • 1 sampling template
  • 1 product qualification certificate
  • 1 user manual
  • 1 delivery note
  • 1 acceptance certificate
