byk-gardner scrub abrasion tester
Wet Abrasion Scrub TesterIntroduction
The painted or uncoated surface need use a brush, sponge, scouring pad, sandpaper or other methods to test the resistance to scrub. The friction test can be carried out by adding a friction agent or a cleaning agent in a wet scrubbing manner. It is usually used in interior wall coatings, floor tiles, shower baths, and furniture.
Wet abrasion scrub resistance testerFeatures
◆Make a uniform reciprocating linear motion by certain progress; with strong reproducibility
◆ 7-inch touch screen display, easy to operate; compact design
◆Using chain drive mechanism to ensure long-term reliable operation
Standard：
ASTM D1792;ASTM D2198;ASTM D2486;ASTM 3206;
ASTM D3207;ASTM D3450;ASTM D4213;ASTM D4488;
ASTM D4828;ISO11998;DIN 53778;DIN 13300;
Canadian Government Regulation 26-GP-3a;
Pennsylvania Federal Code W-4; US Federal Code P-C-431a; P-D-220A, etc.
Technical Parameters
| Items |
Parameters |
| Scrub speed |
6 to 60 Reciprocating / minute |
| The number of reciprocating |
Up to 100,000 |
| Scrub test arm |
can be placed up to 3 brushes or cushion bases, improves test efficiency |
| Test arm maximum load |
4kg（8.8lbs） |
| The stroke length |
28cm |
| Power supply |
AC220v 50Hz |
