G247B Color fastness tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
G247B Color fastness tester for ironing sublimation, It is used for the performance test of color fastness to hot pressing resistance ironing and pressing and dry heat (sublimation) of various dyed printing textile materials and textiles. It can also be used to determine the sublimation of color fastness test for chlorine resistance, scorching, yellowing test of bleaching products, and disperse dyes of textiles, as well as water fastness test of reactive dyes, dimensional stability at high tem perature, etc.Besides,it is commonly used in textile and garment fields such as printing and dyeing fabrics, textile auxiliaries, etc., which can effectively control production and test product performance.
G247B Color fastness tester for ironing sublimation
The unique large test panel can improve the test efficiency and make the tester suitable for more test standard requirements. The upper and lower independent temperature control system can ensure the safety and can be used for hot press ironing test and dry heat test, which is flexible and varied.
The new G247B ironing sublimation color fastness tester has a larger test area, which can meet the needs ofusers to test multiple samples in single test. The tester has functions of over temperature protection, overload protection, electric leakage protection, and access control protection,which is safe and reliable.
Standards compliant
GB/T 5718 Textile color fastness test
P01 part: color fastness to dry heat (except hot pressing)
GB/T 6152 Textiles, color fastness test, Colour fastness to hot pressing
JIS L0879 Test method of dyeing color fastness to dry heat
JIS L0850 Colour fastness to hot pressing.
ISO 105 P01 Textiles - Tests for colour fastness - Part P01: colour fastness to dry heat (including heat treatment)
ISO 105 X11 Textiles - Tests for colour fastness - Part X11: Colour fastness to hot pressing
AATCC 117 Colour fastness to dry heat (no pressure)
AATCC 133 Colour fastness to high temperature (hot pressing)
M&S C13 Colour fastness to high temperature (hot pressing)
M&S C10 Dimensional stability test
Major Features
Upper and lower heating module independent temperature control
The upper and lower inde pendent temperature control system adopts PID temperature control program, with features of high temperature control precision, low heating overload efficiency, and equipped with PT 100 temperature sensor.
Floating pressurized design
The floating design is carried out when the load is pressurized, allowing the testing of materials of different thicknesses. The pressure distribution and uniform heating can still be ensured in case of testing thicker materials.
Independent temperature control system
The timer is configured to preset the test time. It is automatically start the test timing once the upper platen is pressed downwards, and the buzzer is configured to prompt the test end.
Unique appearance design
The appearance of the tester is exquisite and beautiful. The insulation around the upper and lower heating plates is designed with insulation material to ensure that the heat of the heating plate is not transmitted to the outer casing, which is safe and reliable.
Field Application
G247B Color fastness tester for ironing sublimation, It is widely used for the hot pressing resistance ironing and pressing of various dyed printing textile materials, dry heat (sublimation) test, textile chlorine resistance, scorching, yellowing test of bleaching products, and water fastness test of reactive dyes, as well as dimensional stability at high temperature.
It is applicable to the performance verification of new products, quality control of the production department, and the of material properties for the third-party testing organization, the product performance verification laboratory, and the quality and technical supervisiondepartment, etc.
Technical Parameters
|
Test hot plate:W100 X D40mm (same of the upper and lower) |
Tem perature control: independent control of the upper and lower |
|
Heating plate metallurgy: high purity aluminum |
Warming-up time: user-defined |
|
Timer: preset time, automatic timing once the upper plate pressing downwards. |
Applicable test: hot pressing, dry heat, dimensional stability |
|
Heating range: ambient temperature -300°℃ |
Time alarming: buzzing alarm |
|
Hot panel pressure:4±1 KPa(40cm2) |
Weight 25kg |
|
Power:220V 1.6Kwindependent control of the upper and lower |
Power supply: 220V 50Hz |
|
Appearance size:400mmX400mmX450mm |
