Vehicle Cabin Air Filter Tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Application Scenarios

The Air Filter Performance Test System is designed for comprehensive testing of automotive cabin air filters and general particulate filtration media. It is suitable for:

Automotive HVAC system filter manufacturers needing precise testing of particulate filtration efficiency.

R&D laboratories conducting filter performance development, optimization, and validation.

Quality inspection centers performing standardized certification and quality assurance tests.

Environmental control and ventilation product developers requiring accurate measurement of airflow resistance and particle capture performance.

Universities and research institutions engaged in filtration efficiency research, dust loading behavior, and airflow dynamics.

This system supports repeatable and highly accurate tests essential for product development, benchmarking, and compliance verification.

Compliant Standards

The system is fully aligned with internationally recognized standards, ensuring reliable and comparable test results:

DIN 71460-1 – Road vehicles — Air filters for passenger compartments — Part 1: particulate matter filtration tests

ISO/TS 11155-1 – Road vehicles — Air filters for occupants' compartments — Part 1: particulate filtration test

GB/T 14295-2019 – Air filters for general ventilation

GB/T 13554-2020 – High-efficiency particulate air (HEPA) filters

Compliance with these standards ensures that all tests follow uniform procedures for airflow, dust loading, particle sizing, and filtration efficiency evaluation.

Technical Parameters

ParameterSpecification
Air Flow Range 70 – 700 m³/h
Pressure Difference Measurement 0 – 1000 Pa
Filter Adapter Size Up to 300 × 600 mm
Test Section Cross-section 180 cm²
Environmental Sensors Temperature, Relative humidity, Atmospheric pressure
Dust Disperser SAG 410/L (2 – 245 g/h)
Aerosol Generator ATM 220
Electrostatic Neutralizer EAN 581
Light Particles Source Laser aerosols
Particle Counter TOPAS spectrometer LAP321
Power Supply 400 V AC, 16 A
Test Bench Size 460 × 120 × 340 cm

Product Advantages

Standards-compliant performance

Fully meets DIN 71460-1, ISO/TS 11155-1, and relevant GB/T standards, ensuring globally comparable and reproducible test results.

High-accuracy particulate filtration measurement

Capable of evaluating filtration efficiency across a wide particle-size spectrum with precision instrumentation.

Comprehensive pressure drop and dust loading evaluation

Precise measurement of pressure difference and filter dust-loading capacity, essential for determining service life and performance.

Advanced environmental monitoring

Equipped with high-accuracy sensors for real-time monitoring of temperature, humidity, and atmospheric pressure, ensuring stable test conditions.

Professional dust and aerosol generation

Uses high-grade components including SAG 410/L dust disperser, ATM 220 aerosol generator, and EAN 581 neutralizer for precise and repeatable particulate challenge conditions.

High-precision particle counting

Integrated TOPAS LAP321 spectrometer provides accurate particle concentration and size distribution measurements.

Ideal for R&D, validation, and quality assurance

Supports automated testing, data logging, and analysis, enabling consistent testing workflows and reducing human error.
