Test system for large filter elements
Standards
ISO 29463-5
Technical parameters
| Measuring range (total penetration) | Up to 0.0005 % |
| Measurement range (size) | 0.02 – 100 µm |
| Volume flow | 40 – 1.500 m3/h -pressurized operation |
| Differential pressure measurement | 0 – 1.200 Pa selectable, 0 – 2.500 Pa selectable, 0 – 5.000 Pa selectable |
| Aerosols | Dusts (e.g., SAE dusts), salts (e.g., NaCl, KCl), liquid aerosols (e.g., DEHS), latex particles |
| Size filter element | 610 • 610 • 610 mm |
Advantages
Accurate, versatile testing
-Measurement according to ISO 29463-5. as well as ISO 16890 (ISO ePM1; ISO ePM2.5) possible in one channel
-Use of measurement technology in FET 100 and FET 300; dual channels on request
-Particularly wide range of application for separation efficiency measurement from 0.02 to 3 µm
•Flexibility and ease of use -Customization of filter adapters, flow channel and measuring ranges possible for optimal test performance
-Modular compact design for big filter elements, low space requirement
-Horizontal design for minimization of particle losses
-Calibration of raw gas/pure gas not necessary, because only one sampling and one measuring device is used
•Safety
-Logged results based on relevant standards
-Factory tested and calibrated test stands
Application areas
Development
•Quality control for
-Cabin filters
-HEPA/ULPA clean room filters
-Cabin air filters
-Engine air filters
-Compressor supply air filters
•Measurement of MPPS according to ISO 29463-5
•Measurement of the fractional separation efficiency according to ISO 16890
•Determination of the pressure loss at different volume flows
