Reciprocating Wear Tester

•

Get a quote：

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Email: serving@qinsun-lab。com

Reciprocating wear Tester - Characteristics evaluation of the material wear resistance, scratch resistance and rub resistance and others

Fix the product on a horizontal countertop and is worn with the horizontal movement of the horizontal platform under specified abrasive and load. According to the principle of leverage, the other end of the test arm is fitted with weight to maintain the balance of the test arm to ensure the accuracy of the surface load of the sample and the reliability of the test results. The height of abrasive and load are adjustable to suit different height samples test. In addition, different friction media can be used to test the wear resistance of different products according to different requirements of customers. The reproducibility of experimental data can help manufacturers effec-tively control production and verify product performance.

1. The LCD screen is used to control and display the test process.

The reciprocating wear times, motion stroke, reciprocating speed and other parameters can be freely set according to user requirements. Different friction head replacement can be achieved through the unique friction arm design.

2. It can accurately control the implementation of pressure according to the principle of leverage balance.

Fully meet the different requirements of different standards for friction form, friction head, pressure, etc., the height of the abrasive and load frame can be adjusted to suit different height samples.

Standards

ASTM F2496: Scratch hardness and adhesion testing for prints/coatings.

ISO 1518-1 & -2: Scratch resistance determination for paints/varnishes (constant/variable loading).

GME 60248: Scratch resistance for automotive interiors and textiles.

D44 1221: Abrasion resistance for fluff surface materials.

D14 1055-2004 & D42 : Wear resistance for organic coatings and plastic parts.

Product Advantages

Dual-Station Efficiency: Simultaneous testing on two independent workstations accelerates workflow and reduces downtime.

Versatile Applications: Ideal for coatings, plastics, automotive interiors, fabrics, and electronic components.

Precision Control: Adjustable stroke (6–120mm), speed (1–100 cycles/min), and pressure (1N–24N) ensure tailored testing.

User-Friendly Interface: LCD screen with real-time parameter display and programmable settings for speed, cycles, and stroke.

Modular Design: Interchangeable friction heads (CS-10. H-18) and weights accommodate diverse testing requirements.

Lever-Balanced Accuracy: Maintains consistent surface load via counterweight-equipped test arms, ensuring repeatability.

Adjustable Height: Abrasive/load rack adapts to samples of varying thicknesses for universal compatibility.

Product Features

Dual Testing Stations: Independent operation with shared control panel for parallel sample evaluation.

LCD Control System: Intuitive interface for setting cycles (1–999.999), stroke length, and speed; displays real-time progress.

Lever-Balance Mechanism: Precision-engineered test arms with adjustable weights (1N, 2N, 2.5N, 5N, 10N, 24N) for ASTM/ISO compliance.

Interchangeable Friction Heads: Includes semicircular (R18) and flat abrasion heads for material-specific wear simulation.

Height-Adjustable Rack: Accommodates samples up to 120mm thick with easy-to-use locking mechanisms.

Comprehensive Kit: Includes brush, sandpaper, stainless-steel abrasive fixings, and spare parts for seamless maintenance.
