G259A Sweating Guarded Hotplate is the most professional, most advanced Thermal and Evaporative Resistance test instrument，simulate the human skin test plate,Automatic water supply system, Wind speed stabilization system,test unit and Climate Chamber completely separated design, Aluminum alloy shell to ensure that won't rust.

Product Description

Technical Specifications

(RCT)Thermal resistance range : 0.002-2 .0 m²K / W

The sample platform lift range :0~50mm automatic lift

Repeatability: ≤ ± 2%

Sample thickness：0~50mm

Resolution: 0.001m²K / W

Test plate area: 254mm × 254mm

(Ret)evaporative Resistance range : 0-1000m²Pa / W

Guard ring size: 512mm × 512mm

Repeatability: ≤ ± 2%

Guard ring width: 127mm

Resolution: 1m²· Pa / W

Sample size:500mm*500mm

Test plate temperature range: 30 ℃ ~ 40 ℃ adjustable

Dimensions: 73×61×35cm (L x W x H) (not including Climate Chamber)

Temperature control accuracy: ± 0.03 ℃

Weight: 45Kg (not including Climate Chamber)

Temperature measurement: ± 0.01 ℃

Host power: AC220V ± 10%, 100W or AC110V ± 10%, 100W

Air velocity: 0 ~ 1.2 m / s continuously adjustable

Warranty: 24 Months

Air velocity accuracy: ± 1%


Professional Technolog

1.The world's first independent design concept, integrated design of control systems and automatic water supply system, users
can choose the standard Climate Chamber.
2.Automatic water supply, Automatic drain system, Strong feed water system (In the Evaporative Resistance, water uniformly wets
test plate faster)
3.high-precision automatic platform mobile systems, enter the thickness of the test the test platform to move to the corresponding
position.
4.According to the thickness of the sample, the machine automatically adjust the PID control parameters, test conditions can
quickly reach.
5.The patented Air velocity parallel stabilization system, let the Air velocity homogeneous and stable, so that the test results are
more stable.
6.Air velocity continuously adjustable from 0 ~ 1.2m / s to meet any Thermal and Evaporative resistance testing standards.
7.Guard ring width 127mm, to ensure that heat is passed from the test sample.
8. Wifi communication to PC, to make the connection more convenient

Testing standards

GB/T11048
ISO11092
ASTMF1868-09
BS8515
ASTMD1518-2014
JIS L1096-2010
ASTM F 1868-02
