Burning Manikin System| Testing Equipment

•

The burning manikin system is used to test the overall thermal protection performance of protective clothing.Complete combustion manikin system, which consists of combustion chamber, burning manikin and gas control system and other components.

Standard:

EN ISO 11612. EN ISO 11611. ISO 13506. EN469:2005.

ISO13506-1：Protective clothing against heat and flame- part1: Test method for complete garments-Measurement of transferred energy using an instrumented manikin

ISO13506-2：Protective clothing against heat and flame- part2: Skin burn injury prediction- Calculation requirements and test cases

ASTM F1930：Standard test method for evaluation of flame-resistant clothing for protection against fire simulations using an instrumented manikin

GB8965.1，GBT23467

Principle:

The burning manikin system is composed of:

1. computer combustion dummy;

2. thermal sensor group;

3. flame generator;

4. computer control module;

5. data acquisition and processing module;

6. burn analysis module.
