Hexapod Tumbler test machine | Testing Equipment

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Standard

BSEN 1471:1997: Evaluation of Appearance Changes in Floor Coverings

ISO 9405:2001: Floor Coverings – Determination of Appearance Change After Simulated Traffic

ISO 10361:2000: Carpet Appearance Evaluation Using Tumbler Testers

IWS/Wools of New Zealand Methods 247 & 251: Pile Fabric Abrasion Resistance

Application

Textile Industry: Assesses carpet pile integrity for residential, commercial, and automotive applications.

Quality Control: Validates compliance with international appearance change standards.

Research & Development: Tests material resistance to abrasion, crushing, and pile distortion.

Certification Labs: Provides data for SATRA, ISO, and BSEN certification.

Product Advantages

Realistic Wear Simulation: Reciprocating mechanism replicates foot traffic and pile compression.

Rapid Testing: Completes substrate-based barrel tests within one working day.

Adjustable Parameters: Preset rotations (0–999.999 cycles) via digital counter.

Replaceable Components: Polyurethane hexapod feet (3.8 kg) last 2+ years and are easily replaceable.

Safety Design: Hinged cover with sensors prevents accidental access during operation.

Global Compliance: Meets BSEN, ISO, and IWS standards for carpet performance.

Product Features

Hexapod Foot Design: Six polyurethane feet (3.8 kg total) mimic human walking pressure.

Reciprocating Drum: Rotates at 35 ±2 RPM to simulate bidirectional traffic.

Substrate Testing: Accommodates steel balls or textile samples in the 200 mm deep chamber.

Digital Control: Touchscreen panel for cycle preset, speed adjustment, and real-time monitoring.

Easy Maintenance: Quick-release hexapod feet and corrosion-resistant stainless steel drum.

Wall Thickness: 8 mm drum construction ensures durability.

Technical Parameters

ParameterSpecification
Control Panel Touchscreen Timing Module
Hexapod Foot Weight 3.8 kg (Six Polyurethane Feet)
Power Consumption 0.5 kW
Rotational Speed 35 ±2 RPM
Drum Internal Depth 200 ±1 mm
Cycle Counter Range 0–999.999 (Presettable)
Wall Thickness 8 mm (Stainless Steel)
Power Supply AC 220V ±10%, 50Hz
Dimensions (L×W×H) 900 mm × 500 mm × 570 mm
Net Weight 75 kg
Safety Cover

Hinged with Sensor Interlock
