Air Intake Filter Performance Test System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Air Intake Filter Performance Test System is engineered for evaluating the filtration efficiency, airflow characteristics, and dust holding capacity of air intake filters used in automotive engines and industrial systems. The system ensures accurate, repeatable, and internationally comparable results, fully compliant with standards such as ISO 5011, SAE J726, and GB/T 12485. It is suitable for both research and production quality control, enabling detailed analysis of filter performance throughout its service life.
Application
This test system is widely applied in the evaluation of automotive and industrial air filters, engine intake systems, and other air-cleaning components. It is suitable for R&D testing of new filter products, performance verification of different filter brands, and quality inspection by laboratories and production facilities. The system allows comprehensive assessment of filters at various loading stages and operating conditions, providing data critical for product design, certification, and maintenance planning.
Standards
(1) ISO 5011 – Inlet air cleaning equipment for internal combustion engines and compressors.
(2) SAE J726 – Air cleaner test code for automotive and diesel engine filters.
(3) GB/T 12485 – Test methods for air cleaners in internal combustion engines.
(4) ISO 12103-1 – Test dusts (A2 Fine and A4 Coarse) for efficiency and dust holding capacity evaluation.
Features
(1) Multi-functional testing capability including dust holding capacity, restriction vs. flow, initial resistance, incremental efficiency, and full-life efficiency.
(2) Automated and intelligent control system integrating electronic weighing, airflow, and pressure monitoring for real-time data acquisition.
(3) High-precision nozzle flow meter with automatic range switching for accurate airflow measurement.
(4) Compact and modular design compatible with various filter sizes and shapes using custom adapters.
(5) Reliable filtration system equipped with reinforced absolute filters (F8 V-bank) ensuring stable airflow and accurate measurements under load.
(6) Fully automated test sequences with step-by-step guidance to minimize operator errors.
(7) Integrated software enabling real-time visualization, automated report generation, historical data storage, and remote monitoring.
Technical Parameters
| Item | Parameter | Value |
|---|---|---|
| Air flow rate | m³/h | 500 – 4800 (customizable) |
| Pressure drop | Pa | 0 – 10000 |
| Testable filter size | – | Unlimited for assemblies; adapters available for elements |
| Test dust | – | ISO 12103-1 A2 (Coarse) / A4 (Fine) |
| Dust feeder | – | QS-189 |
| Dimensions (with FFU) | mm | 6500 × 3500 × 1800 |
| Power supply | V, A | 400 VAC, 125 A |
| Control system | – | PLC + PC automation with touch interface |
