Single Wire Cable Burning Tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Single Wire Cable Burning Tester is a precision flammability test system designed to assess the flame-retardant performance of single wires and cables under controlled laboratory conditions. It provides stable flame generation, accurate sample positioning, and automated monitoring for repeatable and reliable results. The instrument is widely used in electrical, electronics, and appliance industries to ensure product compliance with international safety standards.

Application

(1) Flammability testing of single wires and cables with conductor diameters >8 mm (cross-sectional area >0.5 mm²).

(2) Flammability testing of single wires and cables with conductor diameters

(3) Research and development of flame-retardant wire and cable materials.

(4) Quality control and inspection in manufacturing of wires, cables, and associated electrical components.

(5) Testing components of household appliances, low-voltage electrical appliances, lighting equipment, motors, power tools, electrical instruments, and connectors.

(6) Certification testing to meet international and national flame-retardancy standards.

Standards

(1) IEC 60332 – Tests on electric and optical fiber cables under fire conditions.

(2) GB/T 19666-2005 – Flame retardant performance of single wires and cables.

(3) GB 12972 – Test method for burning characteristics of wires and cables.

(4) GB 13033 – Vertical flame test for insulated wires and cables.

(5) MT 818 – Military standard for electrical wire flammability.

(6) MT 386 – Standard for wire and cable flame testing.

(7) ISO 5656 – International method for flame testing of electrical cables.

Features

(1) Stable Bunsen burner flame with adjustable height (20 mm – 190 mm) for precise testing.

(2) Movable test beam with 45° inclination for accurate positioning relative to cable diameter and thickness.

(3) Programmable flame duration (0–999.9 s) for repeatable test cycles.

(4) Supports high-purity propane gas or liquefied petroleum gas as combustion source.

(5) Suitable for wires and cables of 600 ± 25 mm length.

(6) Durable electrostatic sprayed steel construction for long-term laboratory use.

(7) Easy-to-operate controls for adjusting gas and airflow rates.

(8) Compact dimensions for laboratory integration (L × W × H: 60 × 45 × 156 cm).

Technical Parameters

ParameterSpecification
Burner Inner Diameter Φ9.5 mm ± 0.5 mm
Test Inclination Angle 45°, beam movable back and forth
Flame Height 20 mm ± 2 mm – 190 mm ± 1 mm, adjustable
Flame Time 0–999.9 s ± 0.1 s, adjustable
Combustion Gas 95% propane gas (or liquefied petroleum gas)
Gas Supply User-supplied high-purity propane or LPG
Tested Wire/Cable Length 600 ± 25 mm
Burner Power 1 kW
Supply Voltage 220 V / 50 Hz
Gas Flow 0–1 L/min
Air Flow 1.5–15 L/min
Box Material Steel with electrostatic spraying
Dimensions (L × W × H) 60 × 45 × 156 cm
