Cylindrical Battery In-Situ Volume Swelling Testing System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Cylindrical Battery In-Situ Volume Swelling Testing System is designed for real-time measurement and analysis of volume and dimensional changes of cylindrical lithium-ion cells during charge and discharge processes. The system uses non-contact laser displacement technology to accurately capture micro-level swelling behavior under controlled temperature and pressure conditions. It provides reliable data support for safety evaluation, reliability testing, and structural optimization of cylindrical batteries.
Application
(1) In-situ volume swelling analysis of cylindrical lithium-ion batteries during cycling.
(2) Expansion behavior evaluation of 18650, 21700, and similar cylindrical cell formats.
(3) Safety and reliability assessment under fast charge, overcharge, and abuse conditions.
(4) Thermal-mechanical coupling analysis under elevated or low-temperature environments.
(5) Fatigue and pressure response testing during long-term cycling.
(6) R&D validation and quality comparison for different cell designs and materials.
Standards
(1) UL 1642 – Standard for Lithium Batteries.
(2) IEC 62660-2 – Secondary Lithium-Ion Cells for the Propulsion of Electric Road Vehicles – Reliability and Abuse Testing.
(3) ASTM E83 – Verification of Linear Displacement Measuring Systems.
(4) ISO 12417-1 – Mechanical Testing of Metals – Dilation Test (reference method).
(5) CE Certification – Conformité Européenne.
Parameters
| Parameter | Specification |
|---|---|
| Displacement Range | ±1 mm (linear), ±0.5° (angular) |
| Linear Measurement Accuracy | ±0.1 μm |
| Angular Measurement Accuracy | ±0.01° |
| Displacement Resolution | 0.05 μm |
| Temperature Range | -20°C to 150°C |
| Temperature Ramp Rate | ≤ 2°C/min |
| Pressure Range | 0–30 bar |
| Test Channels | 4 channels |
| Data Acquisition Rate | 5,000 points/s/channel |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Dimensions (W×D×H) | 600 × 500 × 1000 mm |
| Weight | 150 kg (net) / 180 kg (gross) |
